Case 1 (V, Phase, Hz)
50 Hz 380-415 V 3N~
Limit Range of Voltage(Case 1) (V)
342 - 456
Case 2 (V, Phase, Hz)
60 Hz 380 V 3N~
Limit Range of Voltage(Case 2) (V)
342 - 418
Rated (kW)
39.2
Rated (Btu/h)
133 800
Rated (kW)
39.2
Rated (Btu/h)
133 800
Rated (kW)
10.60
Rated (kW)
11.60
EER(Rated) (W/W)
3.70
COP(Rated) (W/W)
3.38
Rated
0.93 / 0.93
Type
Propeller fan
Air Flow Rate(High) (m³/min x No.)
240 x 1
Discharge direction(Side / Top)
TOP
Type
BLDC
Drive
DC INVERTER
Output (W x No.)
1,200 x 1
Type
Hermetically Sealed Scroll
Piston Displacement (cm³/rev)
62.1
Number of Revolution (rev./min)
3600
Motor Output (W x No.)
5300 x 1
Starting Method
Inverter
Oil Type
FW68D(PVE)
Type
Fin & Tube
No.
1
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
930 x 1690 x 760
Shipping(W x H x D) (mm)
960 x 1825 x 796
Net (kg)
184
Shipping (kg)
196
Color
Morning Gray / Dawn Gray
RAL (Classic)
RAL 7038 / RAL 7037
High Pressure Prevention
High pressure sensor / High pressure switch
Frost Prevention
O
Discharge Tempreature Control
O
Compressor/Fan Protection
Over-heat protection / Fan driver overload protector
Inverter Protection
Over-heat protection / Over-current protection
Type
R410A
Precharged Amount (kg)
7.5
GWP(Global Warming Potential)
2087.5
t-CO₂ eq.
15.656
Control Type
Electronic Expansion Valve
Liquid (mm(inch))
Φ12.7 (1/2)
Gas (mm(inch))
Φ28.58 (1-1/8)
Liquid
Brazing
Gas
Brazing
Cooling / Heating (dB(A))
60 / 61
Measurement Standard (Pressure Level)
ISO 3745
Cooling / Heating (dB(A))
82 / 83
Measurement Standard (Power Level)
ISO 9614
Communication Cable(VCTF-SB) (mm² × cores)
1.0 ~ 1.5 × 2C
Minimium Circuit Amperes (MCA) (A)
26.1
Maximum Fuse Amperes (MFA) (A)
32
Total Over Current Amperes (TOCA) (A)
29
Comp_Maximum Starting Current (MSC) (A)
5.9
Comp_Rated Load Amperes (Cooling) (A)
14.8
Comp_Rated Load Amperes (Heating) (A)
16.5
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
2.5
Max. (Conditional) (EA)
23(35)
