Case 1 (V, Phase, Hz)
50/60 Hz 380-415 V 3N~
Limit Range of Voltage(Case 1) (V)
342 - 456
Case 2 (V, Phase, Hz)
60 Hz 380 V 3N~
Limit Range of Voltage(Case 2) (V)
342 - 418
Rated (kW)
33.6
Rated (Btu/h)
114600
Rated (kW)
8.90
EER(Rated) (W/W)
3.78
Rated
0.93 / -
Type
Propeller fan
Air Flow Rate(High) (m³/min x No.)
240 x 1
Discharge direction(Side / Top)
TOP
Type
BLDC
Drive
DC INVERTER
Output (W x No.)
1200 x 1
Type
Hermetically Sealed Scroll
Piston Displacement (cm³/rev)
62.1
Number of Revolution (rev./min)
3600
Motor Output (W x No.)
5300 x 1
Starting Method
Inverter
Oil Type
FW68L(PVE)
Type
Fin & Tube
No.
1
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
930 x 1690 x 760
Shipping(W x H x D) (mm)
960 x 1825 x 796
Net (kg)
164
Shipping (kg)
174
Color
Morning Gray / Dawn Gray
RAL (Classic)
RAL 7038 / RAL 7037
High Pressure Prevention
High pressure sensor / High pressure switch
Discharge Tempreature Control
O
Compressor/Fan Protection
Over-heat protection / Fan driver overload protector
Inverter Protection
Over-heat protection / Over-current protection
Type
R410A
Precharged Amount (kg)
4.7
GWP(Global Warming Potential)
2087.5
t-CO₂ eq.
9.811
Control Type
Electronic Expansion Valve
Liquid (mm(inch))
Φ12.7 (1/2)
Gas (mm(inch))
Φ28.58 (1-1/8)
Liquid
Brazing
Gas
Brazing
Cooling / Heating (dB(A))
59 / -
Measurement Standard (Pressure Level)
ISO 3745
Cooling / Heating (dB(A))
79 / -
Measurement Standard (Power Level)
ISO 9614
Communication Cable(VCTF-SB) (mm² × cores)
1.0~1.5 X 2C
Minimium Circuit Amperes (MCA) (A)
23.3
Maximum Fuse Amperes (MFA) (A)
25
Total Over Current Amperes (TOCA) (A)
25
Comp_Maximum Starting Current (MSC) (A)
5.9
Comp_Rated Load Amperes (Cooling) (A)
12.0
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
2.5
Max. (Conditional) (EA)
20(30)
