Case 1 (V, Phase, Hz)
50/60 Hz 380-415 V 3N~
Limit Range of Voltage(Case 1) (V)
342 - 456
Case 2 (V, Phase, Hz)
60 Hz 380 V 3N~
Limit Range of Voltage(Case 2) (V)
342 - 418
Rated (kW)
56
Rated (Btu/h)
191100
Rated (kW)
14.10
EER(Rated) (W/W)
3.97
Rated
0.93 / -
Type
Propeller fan
Air Flow Rate(High) (m³/min x No.)
320 x 1
Discharge direction(Side / Top)
Top
Type
BLDC
Drive
DC INVERTER
Output (W x No.)
900 × 2
Type
Hermetically Sealed Scroll
Piston Displacement (cm³/rev)
87.6
Number of Revolution (rev./min)
3600
Motor Output (W x No.)
7,500 x 1
Starting Method
Inverter
Oil Type
FW68L(PVE)
Type
Fin & Tube
No.
1
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
1240 x 1690 x 760
Shipping(W x H x D) (mm)
- x - x -
Net (kg)
221
Shipping (kg)
233
Color
Morning Gray / Dawn Gray
RAL (Classic)
RAL 7038 / RAL 7037
High Pressure Prevention
High pressure sensor / High pressure switch
Discharge Tempreature Control
O
Compressor/Fan Protection
Over-heat protection / Fan driver overload protector
Inverter Protection
Over-heat protection / Over-current protection
Type
R410A
Precharged Amount (kg)
7.5
GWP(Global Warming Potential)
2087.5
t-CO₂ eq.
15.656
Control Type
Electronic Expansion Valve
Liquid (mm(inch))
Φ15.88 (5/8)
Gas (mm(inch))
Φ28.58 (1-1/8)
Liquid
Brazing
Gas
Brazing
Cooling / Heating (dB(A))
63 / -
Measurement Standard (Pressure Level)
ISO 3745
Cooling / Heating (dB(A))
86 / -
Measurement Standard (Power Level)
ISO 9614
Communication Cable(VCTF-SB) (mm² × cores)
1.0 ~1.5 X 2C
Minimium Circuit Amperes (MCA) (A)
35.5
Maximum Fuse Amperes (MFA) (A)
40
Total Over Current Amperes (TOCA) (A)
39.0
Comp_Maximum Starting Current (MSC) (A)
7.5
Comp_Rated Load Amperes (Cooling) (A)
20.5
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
2.5
Max. (Conditional) (EA)
32(50)
