Case 1 (V, Phase, Hz)
380~415, 3, 50
Limit Range of Voltage(Case 1) (V)
342 ~ 456
Case 2 (V, Phase, Hz)
380, 3, 60
Limit Range of Voltage(Case 2) (V)
342 ~ 418
Rated (kW)
67.2
Rated (Btu/h)
229,300
Rated (kW)
74.3
Rated (Btu/h)
253,400
Rated (kW)
15.90
Rated (kW)
18.00
EER(Rated) (W/W)
4.23
COP(Rated) (W/W)
4.13
Rated
0.93 / 0.93
Type
Propeller fan
Air Flow Rate(High) (m³/min x No.)
320 × 1
Max. External Static Pressure (Pa)
80
Discharge direction(Side / Top)
TOP
Type
BLDC
Drive
DC INVERTER
Output (W x No.)
900 × 2
Type
Hermetically Sealed Scroll
Piston Displacement (cm³/rev)
62.1 × 2
Number of Revolution (rev./min)
3,600 × 2
Motor Output (W x No.)
5,300 × 2
Starting Method
Inverter
Oil Type
FW68L(PVE)
Type
Fin & Tube
No.
1
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
1240 x 1745 x 760
Shipping(W x H x D) (mm)
1282 x 1919 x 802
Net (kg)
283
Shipping (kg)
296
Color
Morning Gray / Dawn Gray
RAL (Classic)
RAL 7038 / RAL 7037
High Pressure Prevention
High pressure sensor / High pressure switch
Frost Prevention
O (Logical)
Discharge Tempreature Control
O (Logical)
Compressor/Fan Protection
Over-heat protection / Fan driver overload protector
Inverter Protection
Over-heat protection / Over-current protection
Type
R410A
Precharged Amount (kg)
16.0
GWP(Global Warming Potential)
2087.5
t-CO₂ eq.
33.4
Control Type
Electronic Expansion Valve
Liquid (mm(inch))
15.88(5/8)
Gas (mm(inch))
34.9(1-3/8)
Liquid
Brazing
Gas
Brazing
Cooling / Heating (dB(A))
65 / 66
Measurement Standard (Pressure Level)
ISO 3745
Cooling / Heating (dB(A))
88 / 89
Measurement Standard (Power Level)
ISO 9614
Communication Cable(VCTF-SB) (mm² × cores)
2C × 1.0 ~ 1.5
Minimium Circuit Amperes (MCA) (A)
50.0
Maximum Fuse Amperes (MFA) (A)
60
Total Over Current Amperes (TOCA) (A)
56.0
Comp_Maximum Starting Current (MSC) (A)
11.8
Comp_Rated Load Amperes (Cooling) (A)
23.6
Comp_Rated Load Amperes (Heating) (A)
28.0
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
2.5
Max. (Conditional) (EA)
39(61)
