- 精準的色彩表現
- 寬廣顔色可視角
- 使用者體驗更升級
- 清晰極黑影像
- 長距離資料傳輸
所有規格
資訊
型號名稱
LMPA009BANA.ATT
物理參數
像素配置
Micro
像素間距 (mm)
0.94
模組解析度 (WxH)
320x120
模組尺寸(WxH,mm)
300x112.5
單一模組重量 (kg)
0.19
單一箱體模組數 (WxH)
2x3
箱體解析度 (WxH)
640x360
箱體尺寸(W x H x D,mm)
600x337.5x39.8
箱體表面積 (㎡)
0.2
箱體重量(kg/台)
5.2
每平方公尺重量 (kg/㎡)
25.7
物理像素密度(像素/㎡)
1,137,778
箱體平坦度 (mm)
±0.5
箱體材質
Mold / PC+ABS-GF20%
服務進入點
Front
光學規格
最大亮度(校準後,nit)
Typ. 600 / Peak 1,500
色溫 (K)
3,200~9,300 / Default 7,300
視角(橫向)
160
視角(縱向)
160
亮度均勻度
0.95
色彩均勻度
±0.02Cx,Cy
處理深度(位元)
20 (HDR10, HDR10 Pro)
電氣 規格
供電 (V)
100 to 240
幀率 (Hz)
50 / 60
更新率 (Hz)
7,860
運作 規格
作業溫度 (℃)
0℃ to +40℃
作業濕度
10~80%RH
IP 等級正面
IP50
IP 等級背面
IP20
LED 使用壽命(半亮度)
100,000
標準
認證
Safety 62368-1, EMC Class B, BS476 Part7 Class1
環境
環境
RoHs
控制器
控制器
CEAC / SBAA-D05
90 度切角
90 度切角
NO
