32" TV Signage
All Spec
DISPLAY
Inch
32H"
Resolution
1,366 x 768 (HD)
Backlight Unit Type
Direct
Brightness (cd/m²)
240
BROADCASTING SYSTEM
Digital
Yes (DVB-T2 / C / S2)
AUDIO
Audio Output
5W + 5W
Speaker System
2.0 ch
HOSPITALITY SOLUTION
Solution Type
Pro:Centric (V), Quick Menu 3.0
Data Streaming (IP &RF)
Yes (RF Only)
HCAP (GEM/FLASH/HTML)br※ Service Carousel (TLL/XML)
GEM
Pro:Centric Server
PCS400R, PCS200R
FEATURES
Hospitality
EzManager (Simplicity), USB Cloning, Self Diagnostics(USB), HTNG-CEC, Simplink (HDMI-CEC, 1.4), IR Out (RS-232C), Multi IR Code, Hotel Mode, Lock mode (Limited), Welcome Video / Screen, Insert Image, One Channel Map, External Speaker Out (Int / Fixed, 3.5mm, Stereo, Single ended Type(GND, L+, R+), 2W with 8Ω), RJP (Remote Jack Pack) Compatibility, USB Auto playback, Auto Off / Sleep Timer, Smart Energy Saving, Motion Eye Care, Healthcare Headphone Mode, Time Scheduler, Anti-theft System (Kensington Lock, Credenza / Security Screw Hole, Lock Down Plate)
JACK INTERFACE
Set Side
Headphone Out, HDMI In (1.4), USB 2.0, CI Slot
Set Rear
HDMI In (HDCP, 1.4), USB, RF In (2), AV In (Phone Jack Type), Component in (RCA5 Type), Digital Audio Out (Optical), RGB In (D-sub 15pin) - PC, RS-232C (D-Sub 9pin, Control & Service), RJ45 (Usage Purpose, SNMP& Service), RJ45 (Usage Purpose, SNMP&MHEG), External Speaker Out (3.5 mm Phone Jack)
DIMENSION(UNIT: MM/KG)
Vesa
200 x 200
W x H x D / Weight (with stand)
739 x 495 x 241 / 6.05
W x H x D / Weight (without stand)
739 x 441 x 74.6 (84) / 4.85
W x H x D / Weight (Shipping)
905 x 530 x 162 / 7.35
POWER(UNIT : WATTS)
Voltage, Hz
100 ~ 240, 50 / 60
Typical
34.0
Stand-by
0.3
GENERAL
Region
Europe
