Ceiling Cassette, 4 Way Dual Vane, Indoor Unit, 30kBtu/h

Ceiling Cassette, 4 Way Dual Vane, Indoor Unit, 30kBtu/h

ARNU30GTBB4
  • LG Dual Vane Cassette, Indoor Unit, ARNU30GTBB4 is a square shape, and air can extend in four ways.
LG Dual Vane Cassette, Indoor Unit, ARNU30GTBB4 is a square shape, and air can extend in four ways.

Key Features

  • 4 Way Air Flow with New Design
  • Convenient & Powerful 5-step Air Purification (Optional)
  • Human Detection Air Flow (Optional)

4 Way Air Flow

New dual vane 4-way cassette allows comfortable and convenient air flow. It operates 6 airflow modes including power mode, smart mode and refresh mode.

5-Step Air Purification (Optional)

A powerful air purification removes odor, germs, and invisible PM 1.0 fine dust. It is easy to manage air purification system with one-touch air purification filter.

Human Detection (Optional)

Human detection provides users with direct or indirect air flow preferences.

Print

All Spec

POWER SUPPLY

  • Case 1

    50/60 Hz 220-240 V~

  • Limit Range of Voltage(Case 1) (V)

    240, 230, 220

  • Case 2

    50/60 Hz 220-240 V~

COOLING CAPACITY

  • Nominal (kW)

    9.00

  • Nominal (Btu/h)

    30700

HEATING CAPACITY

  • Nominal (kW)

    10.0

  • Nominal (Btu/h)

    34100

POWER INPUT(INDOOR)

  • H/M/L (W)

    48 / 36 / 25

RUNNING CURRENT(INDOOR)

  • H/M/L (A)

    0.43 / 0.34 / 0.25

INDOOR FAN

  • Type

    3D Turbo Fan

  • Air Flow Rate(H/M/L) (m³/min)

    21 / 19 / 16

INDOOR FAN MOTOR

  • Type

    Brushless DC

  • Drive

    Direct

  • Output (No.)

    1

  • Output (W)

    51

HEAT EXCHANGER

  • Rows x Columns x FPI

    3 x 8 x 21

  • No.

    1

  • Face Area (m²)

    0.33

DIMENSIONS

  • Net(W x H x D) (mm)

    840 x 204 x 840

  • Shipping(W x H x D) (mm)

    922 x 276 x 917

WEIGHT

  • Net (kg)

    21

  • Shipping (kg)

    26

EXTERIOR

  • Color

    White

  • RAL (Classic)

    RAL 9003

AIR FILTER

  • Type

    Long life filter

TEMPERATURE CONTROL

  • Temperature Control

    Microprocessor, Thermostat for cooling and heati

SOUND ABSORBING THERMAL INSULATION MATERIAL

  • Sound Absorbing / Thermal Insulation Material

    Foamed polystrene

PROTECTION DIVICE

  • Fuse

    Fuse

REFRIGERANT

  • Type

    R410A/R32

  • Additional Charging amount (kg(each))

    0.32 / 0.26

  • Control Type

    EEV

DRAIN PIPE(USING DRAIN PUMP)

  • O.D / I.D (mm(inch))

    32/25

CONNECTING PIPE

  • Liquid (mm(inch))

    Φ9.52 (3/8)

  • Gas (mm(inch))

    Φ15.88 (5/8)

PIPING CONNECTION TYPE

  • Liquid

    Flare

  • Gas

    Flare

SOUND PRESSURE LEVEL (INDOOR UNIT)

  • Cooling((SH)/H/M/L) (dB(A))

    - / 43 / 40 / 36

  • Heating((SH)/H/M/L) (dB(A))

    43 / 40 / 36

SOUND POWER LEVEL (INDOOR UNIT)

  • Cooling((SH)/H/M/L) (dB(A))

    - / 53 / 50 / 45

  • Heating((SH)/H/M/L) (dB(A))

    53 / 50 / 45

CONNECTING CABLE

  • Communication Cable(VCTF-SB) (mm² × cores)

    1.0~1.5 x 2

ELECTRICAL CHARACTERISTIC

  • Minimium Circuit Amperes (MCA) (A)

    1.23

  • Indoor Fan Motor_Full Load Amperes (FLA) (A)

    0.98

PRODUCT

  • Type

    Dual Vane

PRODUCT INFORMATION

To access more technical documentation and resources, please visit the LG B2B partner portal.
