Case 1
50/60 Hz 220-240 V~
Limit Range of Voltage(Case 1) (V)
198-264
Nominal (kW)
14.10
Nominal (Btu/h)
48100
Nominal (kW)
13.5
Nominal (Btu/h)
46100
H/M/L (W)
75 / 47 / 47
H/M/L (A)
0.45 / 0.43 / 0.41
Type
Sirocco Fan
Air Flow Rate(Cooling,(SH)/H/M/L) (m³/min)
-/20/13.2/13.2
Air Flow Rate(Heating,(SH)/H/M/L) (m³/min)
-/20/13.2/13.2
External Static Pressure(Factory Set) (Pa)
59
Type
BLDC
Drive
Direct
Output (W)
400
Output (No.)
1
Net(W x H x D) (mm)
1,250 × 360 × 700
Shipping(W x H x D) (mm)
1450 x 428 x 773
Net (kg)
42.6
Shipping (kg)
48.3
Temperature Control
Microprocessor, Thermostat for cooling and heating
Sound Absorbing / Thermal Insulation Material
Foamed polystrene
Fuse
Fuse
Type
R410A
Additional Charging amount (kg(each))
0.61
Control Type
EEV
O.D / I.D (mm(inch))
- / 25(1)
Liquid (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ15.88 (5/8)
Cooling((SH)/H/M/L) (dB(A))
-/38/36/36
Heating((SH)/H/M/L) (dB(A))
-/38/36/36
Measurement Standard (Pressure Level)
ISO 3745
Communication Cable(VCTF-SB) (mm² × cores)
1.0~1.5 × 2C
Minimium Circuit Amperes (MCA) (A)
3.1
Indoor Fan Motor_Full Load Amperes (FLA) (A)
2.5
Type
Fresh Air Intake
