Case 1 (V, Phase, Hz)
50/60 Hz 220-240 V~
Limit Range of Voltage(Case 1) (V)
198-264
Rated (kW)
14
Rated (Btu/h)
47800
Rated (kW)
16
Rated (Btu/h)
54 600
Rated (kW)
3.33
Rated (kW)
3.48
EER(Rated) (W/W)
4.20
COP(Rated) (W/W)
4.60
Rated
0.93/0.93
Type
Axial Flow Fan
Air Flow Rate(High) (m³/min x No.)
80 x 1
Discharge direction(Side / Top)
Side
Type
BLDC
Drive
DC Inverter
Output (W x No.)
198 x 1
Type
LG Inverter Scroll
Piston Displacement (cm³/rev)
31.6
Number of Revolution (rev./min)
3600
Motor Output (W x No.)
3 198 x 1
Starting Method
DC Inverter Strarting
Oil Type
FW68D
Type
Fin & Tube
No.
1
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
950 x 834 x 330
Shipping(W x H x D) (mm)
1147 x 919 x 461
Net (kg)
72
Shipping (kg)
80
Color
Warm Gray
RAL (Classic)
RAL 7044
High Pressure Prevention
O
Frost Prevention
O
Discharge Tempreature Control
O
Compressor/Fan Protection
Over Heat Protection/Fan Driver overload protector
Inverter Protection
Over Heat Protection/ Over Current protection
Type
R410A
Precharged Amount (kg)
2.4
t-CO₂ eq.
5.010
Control Type
Electronic Expansion Valve
Liquid (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ15.88 (5/8)
Liquid
Flare
Gas
Flare
Cooling / Heating (dB(A))
57/60
Measurement Standard (Pressure Level)
ISO 3745
Cooling / Heating (dB(A))
70/74
Measurement Standard (Power Level)
ISO 9614
Communication Cable(VCTF-SB) (mm² × cores)
1.0~1.5 x 2
Minimium Circuit Amperes (MCA) (A)
25.0
Maximum Fuse Amperes (MFA) (A)
30
Total Over Current Amperes (TOCA) (A)
27.6
Comp_Rated Load Amperes (Cooling) (A)
15.4
Comp_Rated Load Amperes (Heating) (A)
16.1
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
0.9
Max. (Conditional) (EA)
10
