Case 1 (V, Phase, Hz)
50 Hz 380-415 V 3N~
Limit Range of Voltage(Case 1) (V)
342~456
Case 2 (V, Phase, Hz)
60 Hz 380 V 3N~
Rated (kW)
28
Rated (Btu/h)
95900
Rated (kW)
31.5
Rated (Btu/h)
107500
Rated (kW)
7.09
EER(Rated) (W/W)
3.95
COP(Rated) (W/W)
4.38
Rated
0.93/0.93
Type
Propeller fan
Air Flow Rate(High) (m³/min x No.)
190
Discharge direction(Side / Top)
Side
Type
BLDC
Drive
DC INVERTER
Output (W x No.)
250 x 2
Type
Hermetically Sealed Scroll
Motor Output (W x No.)
5,300 x 1
Oil Type
FVC68D(PVE)
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
1090 x 1625 x 380
Shipping(W x H x D) (mm)
1210 x 500 x 1780
Net (kg)
142
Shipping (kg)
158
High Pressure Prevention
High pressure sensor / High pressure switch
Frost Prevention
O (Logical)
Discharge Tempreature Control
O (Logical)
Compressor/Fan Protection
Over-heat protection / Over-current protection
Inverter Protection
Over-heat protection / Over-current protection
Type
R410A
Precharged Amount (kg)
4.5
Control Type
Electronic Expansion Valve
Liquid (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ22.22 (7/8)
Cooling / Heating (dB(A))
58/58
Cooling / Heating (dB(A))
70/70
Communication Cable(VCTF-SB) (mm² × cores)
1.0~1.5 x 2
Max. (Conditional) (EA)
16
