Case 1 (V, Phase, Hz)
50 Hz 380-415 V 3N~
Limit Range of Voltage(Case 1) (V)
342 ~ 456
Case 2 (V, Phase, Hz)
60 Hz 380 V 3N~
Limit Range of Voltage(Case 2) (V)
342 ~ 418
Running Current by Voltage (Cooling,Rated) (A)
13.72 - 13.04 - 12.57
Running Current by Voltage (Heating,Rated) (A)
14.25 - 13.53 - 13.04
Rated (kW)
50.4
Rated (Btu/h)
172000
Rated (kW)
56.7
Rated (Btu/h)
193500
Rated (kW)
8.40
Rated (kW)
8.72
EER(Rated) (W/W)
6.00
COP(Rated) (W/W)
6.5
Rated
0.93/0.93
Type
Hermetically Sealed Scroll
Piston Displacement (cm³/rev)
62.1
Number of Revolution (rev./min)
3600
Motor Output (W x No.)
5300 x 1
Starting Method
Direct On Line
Oil Type
FW68D(PVE)
Type
Stainless Steel Plate
Maximum Pressure Resistance (kg/cm²)
45
Rated Water Flow ( LPM )
173
Min.~Max. (LPM)
96.0 - 240.0
Head loss ( kPa )
24.6
Net(W x H x D) (mm)
772 x 1120 x 547
Shipping(W x H x D) (mm)
820 x 1245 x 645
Net (kg)
158 x 1
Shipping (kg)
166 x 1
Color
Morning Gray / Dawn Gray
RAL (Classic)
RAL 7038 / RAL 7037
High Pressure Prevention
High pressure sensor / High pressure switch
Discharge Tempreature Control
Over-heat protection
Inverter Protection
Over-heat protection / Over-current
protection
Type
R410A
Precharged Amount (kg)
4.5
GWP(Global Warming Potential)
2,087.5
t-CO₂ eq.
9.394
Control Type
Electronic expansion valve
Liquid (mm(inch))
Φ15.88 (5/8)
Gas (mm(inch))
Φ28.58 (1-1/8)
Low Pressure Gas (Heat Recovery) (mm(inch))
Φ28.58 (1-1/8)
High Pressure Gas (Heat Recovery) (mm(inch))
Φ22.22 (7/8)
Liquid
Brazing
Gas
Brazing
Low Pressure Gas (Heat Recovery)
Brazing
High Pressure Gas (Heat Recovery)
Brazing
Inlet (mm)
PT 40 (Internal Thread)
Outlet (mm)
PT 40 (Internal Thread)
Drain Outlet (mm)
PT 20 (External Thread)
Cooling / Heating (dB(A))
54 / 57
Measurement Standard (Pressure Level)
ISO 3741
Cooling / Heating (dB(A))
66 / 69
Communication Cable(VCTF-SB) (mm² × cores)
1.0 ~ 1.5 × 2C
Minimium Circuit Amperes (MCA) (A)
30
Maximum Fuse Amperes (MFA) (A)
35
Total Over Current Amperes (TOCA) (A)
31
Comp_Rated Load Amperes (Cooling) (A)
13.49
Comp_Rated Load Amperes (Heating) (A)
14.25
Max. (Conditional) (EA)
29(45)
Min. / Max. (Conditional) (%)
50~130(200)
