- Brightness(Typ.) : 250 cd/m²
- Bezel : 16.3mm
- Depth : 53.8mm
- Interface : HDMI(2) / USB 2.0 / RS232C / RJ45 / IR / Audio
- USB Plug & Play, Built-in Wi-Fi
All Spec
PANEL
Screen Size
21.5"
Panel Technology
IPS
Native Resolution
1,920 x 1,080 (FHD)
Brightness
250 nit (Typ.)
Contrast Ratio
1,000:1
Dynamic CR
400,000:1
Color gamut
BT.709 95%
Viewing Angle(H x V)
178 X 178
Color Depth
6bit, 16.7Million Colors
Response Time
14ms (G to G)
Surface Treatment(Haze)
25%
Operation Hours (Hours/Day)
16/7
Portrait / Landscape
No / Yes
CONNECTIVITY
Input - Digital - HDMI
Yes(2), HDCP2.2
Input - Audio In
Yes(1)
Input - External Control - RS232C IN
Yes(1), Phone-jack
Input - External Control - RJ45(LAN)
Yes(1)
Input - External Control - IR IN
Yes(1), Phone-jack
Input - USB
USB2.0 Type A(1)
MECHANICAL SPECIFICATION
Bezel Color
Black
Bezel Width
Even Bezel 16.3mm
Weight(Head)
3.34 kg
Monitor Dimension(W x H x D)
510.3 x 302.1 x 53.8mm
VESA™ Standard Mount Interface
100 x 100
ENVIRONMENT CONDITIONS
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
POWER
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power
SOUND
Speaker
Yes(1W x 2EA)
ACCESSORY
Basic
Remote Controller, Power Cord, QSG, HDMI Cable, Phone to RS232C Gender, External IR, IR Sheet
KEY FEATURE
HW - Internal Memory
8GB
HW - Wi-Fi - Built-in
Yes
HW - Sensor - Temperature Sensor
Yes
HW - Local Key Operation
Yes
SW - webOS ver.
webOS 4.1
SW - Embedded CMS - Local Contents Scheduling
Yes
SW - Embedded CMS - Group Manager
Yes
SW - USB Plug & Play
Yes
SW - Fail over
Yes
SW - Background Image - Booting Logo Image
Yes
SW - Background Image - No Signal Image
Yes
SW - Multi-screen - PIP
Yes
SW - Multi-screen - PBP
Yes(2)
SW - Screen Share
Yes
SW - Video Tag
Yes(2)
SW - Play via URL
Yes
SW - Gapless Playback
Yes
SW - Setting Data Cloning
Yes
SW - SNMP
Yes
SW - ISM Method
Yes
SW - Status Mailing
Yes
SW - Control Manager
Yes
SW - 3rd Party Compatibility - Crestron Connected<sup>®</sup>
Yes (Network Based Control)
SW - Smart Energy Saving
Yes
SW - PM mode
Yes
SW - Wake on LAN
Yes
SW - Beacon
Yes
SW - HDMI-CEC
Yes (Compatibility may differ by equipment.)
SW - SI Server Setting
Yes
SW - webRTC
Yes
SW - Pro:Idiom
Yes
POWER CONSUMPTION
Typ.
30W
Max.
33W
BTU (British Thermal Unit)
7.17(Typ), 7.89(Max)
CERTIFICATION
Safety
CB / NRTL
EMC
FCC Class "A" / CE
ErP
Yes (EU Only)
SOFTWARE COMPATIBILITY
SuperSign CMS
Yes
SuperSign Control / Control+
Yes / Yes
SuperSign WB
Yes
SuperSign Media Editor
Yes
Signage 365 Care
Yes (The availability can differ by region.)
