One:Quick Works for Zoom Rooms

55CT5WN-Z

Key Features

Resolution : 4K Ultra HD (3,840 x 2,160)
Brightness : 450 nit
BuIlt-in Camera & Microphone
Sound (10W + 10W)
In-Cell Touch (Max. 10 Points) & Whiteboard Support
Zoom Rooms App Preloaded

All Spec

PANEL

Screen Size: 55"

Panel Technology: U-IPS

Native Resolution: 3840x2160 (UHD)

Brightness: 450nit

Contrast Ratio: 1000:1

Color gamut: NTSC 72%

Viewing Angle(H x V): 178x178

Color Depth: 10-bit(D),1.07 Billion colors

Response Time: 9ms

Surface Treatment(Haze): Haze 12% (Enhanced in-TOUCH Pol.)

Operation Hours (Hours/Day): 24/7

Portrait / Landscape: No / Yes

CONNECTIVITY

Input: HDMI (2), DP (USB Type C), RJ45(LAN), USB (USB3.1 Type A(2), USB Type C)

Output: DP Out (1, USB Type C (DP ALT MODE))

MECHANICAL SPECIFICATION

Bezel Color: Silver

Bezel Width: 57.2 / 26.2 / 26.2 / 28.9mm

Weight(Head): 26kg

Monitor Dimension(W x H x D): 1265 x 769.5 x 61.8mm

Monitor Dimensions with Stand(W x H x D): 1265 x 815 x 290mm

VESA™ Standard Mount Interface: 300x300

KEY FEATURE

HW: CPU (AMD Ryzen Embedded V1605B), Graphics (AMD Radeon Vega), Internal Memory (SSD 256GB, RAM 8GB), Wi-Fi (802.11ac 2x2), Bluetooth 5.0, Temperature Sensor, Auto Brightness sensor, Local Key Operation (Jog Key)

SW: OS (Windows 10 IOT Enterprise (Value)), Built-in Apps (Zoom Rooms (Preloaded))

ENVIRONMENT CONDITIONS

Operation Temperature: 0 °C to 40 °C

Operation Humidity: 10 % to 80 %

POWER

Power Supply: AC 100-240V~, 50/60Hz

Power Type: Built-In Power

POWER CONSUMPTION

Typ.: 127W

Max.: 245W

BTU (British Thermal Unit): 72

SOUND

Speaker: Yes (10W x 2)

CERTIFICATION

Safety: CB / NRTL

EMC: FCC Class "B" / CE

ErP: Yes

LANGUAGE

OSD: English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic, Turkish, Polski

ACCESSORY

Basic: Remote Controller(include battery 2ea), Power Cord, Touch Pen, Pen tip, Manual, Regulation Book, Warranty Card, IG

Optional: 2 pole Stand(ST-653TW)

SPECIAL FEATURE

Touch - Available object size for touch: Ø8 mm

Touch - Reponse Time(PC Win10): 35mm ↓

Touch - Accuracy: 3.5mm ↓

Touch - Interface: USB1.1

Touch - Operating System Support: Windows 10 or higher

Touch - Multi touch point: Max 10 Points

CAMERA

Resolution: 3840x2160 (UHD) * In line with the Zoom Rooms app specifications (HD, 720p)

Field of View (FoV): 120°

Zoom (ePTZ): 4x Zoom

Video Framing: Yes

MIC

Array: 10EA

Beamforming: Yes

Pickup Range: 6m

WARRANTY

Global: 3 Years (Panel) 1 Year (PC Board)
