32SM5KB
SM5KB Series
  • Edge-lit LED
  • Brightness : 400 cd/m²
  • Bezel : T/L/R 11.9mm (B 18.0mm)
  • Built-in Speaker : 10W x 10W
  • Depth : 66.8mm
  • 24/7 Operation
SM5KB Series
MSRP AED

PANEL

  • Screen Size
    32"
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness
    400cd/m²

CONNECTIVITY - INTPUT

  • HDMI
    Yes (1), HDMI /HDCP2.2
    DP
    Yes (1), DP /HDCP1.3
  • DVI-D
    Yes (1), HDCP2.2
    Analog (RGB)
    Yes (1)
  • Audio In
    Yes (1), RGB/DVI
    External Control (RS232C IN)
    Yes (1)
  • External Control (RJ45)
    Yes (1)
    External Control (IR receiver)
    Yes (1)
  • External Control (Pixel Sensor)
    Yes (1)
    USB (USB3.0)
    Yes (1)
  • SD Card (SDHC/Full Size)
    Yes (1)

CONNECTIVITY - OUTPUT

  • DP Out
    Yes (1), SST/DP1.2a
    Audio Out
    Yes (1)
  • Externel Speaker Out
    No
    External Control (RS232C OUT)
    Yes (1)

PHYSICAL SPECIFICATION

  • Bezel Width
    11.9mm (T), 12.4mm (R/L), 15.5mm (B)
    Monitor Dimension (W x H x D)
    729.4mm X 428.9mm X 55.5mm
  • Weight (Head)
    5.4kg
    VESA™ Standard Mount Interface
    200mm x 200mm

MEDIA PLAYER COMPATIBILITY

  • OPS Type Compatible
    Yes
    External Media Player Attatchable
    No

SOFTWARE COMPATIBILITY

  • SuperSign-w lite
    Yes
    SuperSign-c
    Yes

ACCESSORY

  • Basic
    Remote Controller (include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover
    Optional
    Stand (ST-322T), Pixel sensor (KT-SP0), Wall bracket (LSW230B), OPS Kit (KT-OPSA), HD Base T (EB-B100)

GENERAL

  • Region
    Global
