Touch Open Frame

New In-Cell Touch Open Frame for Optimal Customization

New In-Cell Touch Open Frame for Optimal Customization1 New In-Cell Touch Open Frame for Optimal Customization2
* All images in this page are for illustrative purposes only.

Slim & Light

The In-Cell Touch Open Frame has a touch function built into the display, allowing for the implementation of a slim design and a narrow bezel compared to general touch products that require additional touch parts (Film).
The conventional display has a touch sensor between the cover glass layer and the CF glass and TFT glass layers, whereas In-cell Touch has a touch sensor between the CF glass layer and the TFT glass layer without a cover glass layer. The conventional display has a touch sensor between the cover glass layer and the CF glass and TFT glass layers, whereas In-cell Touch has a touch sensor between the CF glass layer and the TFT glass layer without a cover glass layer.

Clear Picture Quality

Compared to general touch products, TNF5J implements clear picture quality without milk effects caused by additional touch sensor film parts.
While scenery on the conventional display looks blurry, the image on the In-cell Touch is clear. While scenery on the conventional display looks blurry, the image on the In-cell Touch is clear.

Design Flexibility

By providing integrated parts such as touchscreen, display, and webOS, users can realize free design for their own needs.
Various types of displays using TNF5J such as kiosk displays and publicity displays are placed. Various types of displays using TNF5J such as kiosk displays and publicity displays are placed.

High-Performance with
webOS 6.0

webOS 6.0, upgraded in SoC* and web engine, is available on TNF5J for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI** and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.
A number of tasks that can be done simultaneously are easily arranged through the webOS platform. A number of tasks that can be done simultaneously are easily arranged through the webOS platform.
* SoC : System On Chip
** GUI : Graphical User Interface
PANEL
  • Screen Size
    43"
    Panel Technology
    IPS
  • Native Resolution
    3,840 x 2,160 (UHD)
    Brightness
    450 nit
  • Contrast Ratio
    1,000:1
    Color Gamut
    NTSC 72%
  • Viewing Angle (H x V)
    178 x 178
    Color Depth
    10bit, 1.07Billion colors
  • Response Time
    9ms(G to G)
    Surface Treatment(Haze)
    Low Haze (3%)
  • Operation Hours (Hours/Day)
    24/7
    Portrait / Landscape
    Yes / Yes
CONNECTIVITY(JACK INTERFACE)
  • Input - Digital - HDMI
    Yes(2), HDCP 2.2/1.4
    Input - RS232C IN
    Yes (1)
  • Input - RJ45(LAN)
    Yes (1)
    Input - IR IN
    Yes(1)
  • Input - USB
    USB2.0 Type A(1)
    output - Audio Out
    Yes (1)
  • Output - Touch USB
    USB2.0 Type B(1)
MECHANICAL SPECIFICATION
  • Bezel Color
    Black
    Bezel Width
    9.1/9.1/9.1/16.1mm
  • Weight(Head)
    16.8Kg
    Monitor Dimension(W x H x D)
    1231.8 x 709.6 x 39.2mm
  • VESA™ Standard Mount Interface
    300 x 300
KEY FEATURE
  • HW - Internal Memory
    8GB (System 5GB + Available 2.48GB)
    HW - Sensor - Temperature Sensor
    Yes
  • SW - webOS ver.
    webOS6.0
    SW - Embedded CMS - Local Contents Scheduling
    Yes
  • SW - Embedded CMS - Group Manager
    Yes
    SW - USB Plug & Play
    Yes
  • SW - Fail over
    Yes
    SW - Background Image - Booting Logo Image
    Yes
  • SW - Background Image - No Signal Image
    Yes
    SW - Video Tag
    Yes
  • SW - Play via URL
    Yes
    SW - Rotation - Screen Rotation
    Yes
  • SW - Gapless Playback
    Yes
    SW - Setting Data Cloning
    Yes
  • SW - SNMP
    Yes
    SW - ISM Method
    Yes
  • SW - Status Mailing
    Yes
    SW - Control Manager
    Yes
  • SW - 3rd Party Compatibility - Crestron Inside
    Yes
    SW - Power - Smart Energy Saving
    Yes
  • SW - Power - PM mode
    Yes
    SW - Power - Wake on LAN
    Yes
  • SW - Power - Network Ready
    Yes
    SW - HDMI-CEC
    Yes
  • SW - SI Server Setting
    Yes
    SW - webRTC
    Yes
  • SW - Pro:Idiom
    Yes
ENVIRONMENT CONDITIONS
  • Operation Temperature
    0 °C to 40 °C
    Operation Humidity
    10% to 80%
POWER
  • Power Supply
    AC 100-240V~, 50/60Hz
    Power Type
    Built-In Power
POWER CONSUMPTION
  • Typ.
    127W
    Max.
    170W
  • BTU (British Thermal Unit)
    433 BTU/Hr(Typ.), 580 BTU/Hr(Max.)
CERTIFICATION
  • Safety
    CB / NRTL
    EMC
    FCC Class "A"/ CE / KC
  • ErP / Energy Star
    Yes / No
SOFTWARE COMPATIBILITY
  • SuperSign CMS
    Yes
    SuperSign Control / Control+
    Yes
  • Signage 365 Care
    Yes
Language
  • OSD
    English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic, Turkish, Polski
ACCESSORY
  • Basic
    Power Cord 1.55 M*1, USB Cable (Type A-Type B) 1.8 M*1, User Manual, QSG, Remote Controller(include battery 2ea), RS232C Gender, IR Receiver
SPECIAL FEATURE
  • Touch - Available object size for touch
    Ø6mm ↑
    Touch - Reponse Time (Based on 'Paint' app on Windows 10 PC)
    90ms ↓
  • Touch - Accuracy
    3.5mm±0.5mm
    Touch - Interface
    USB2.0
  • Touch - Operating System Support
    Windows 10
    Touch - Multi touch point
    Max. 10 Points
