ADD TO WISHLIST

NEW
86-inch UHD signage, rotatable, with standard brightness of 350 nits

Key Features

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (86UL3Q-E)
    AED
    AED
    LG Members Price
Total

component-OBScountrySelectDesc

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (86UL3Q-E)
    AED
    AED
    LG Members Price
Total
86-inch UHD signage, rotatable, with standard brightness of 350 nits

LG webOS UHD Signage

A signage display is mounted on the wall of a meeting room, clearly showing meeting content on the screen. A signage display is mounted on the wall of a meeting room, clearly showing meeting content on the screen.
* All images in this page are for illustrative purposes only.
INFO
  • Product
    Standard (UHD)
    Year
    Y24
  • Month
    M05
PANEL
  • Screen Size (Inch)
    86"
    Panel Technology
    ADS
  • Back Light Type
    Direct
    Aspect Ratio
    16:9
  • Native Resolution
    3840 x 2160 (UHD)
    Refresh Rate
    60Hz
  • Brightness
    350nit (Typ.)
    Contrast Ratio
    1,200 : 1
  • Dynamic CR
    1,000,000:1
    Color Gamut
    DCI 80%
  • Viewing Angle (H x V)
    178 x 178
    Color Depth (Number of Colors)
    Advanced 10bit, 1.07 Billion colors
  • Response Time
    8ms (G to G)
    Surface Treatment (Haze)
    1%
  • Life time
    30,000Hrs (Min)
    Operation Hours (Hours/Day)
    16/7
  • Portait / Landscape
    Yes / Yes
CONNECTIVITY(JACK INTERFACE)
  • HDMI IN
    Yes(3), HDCP2.2/1.4
    RS232C IN
    Yes(1), 4pin Phone-jack
  • RJ45(LAN) IN
    Yes(1)
    USB IN
    USB2.0 Type A(2)
  • Audio Out
    Yes(1)
    RS232C Out
    Yes
MECHANICAL
  • Bezel Color
    Black
    Bezel Width
    12.9mm Even
  • Weight (Head)
    31.8
    Packed Weight
    42.6
  • Monitor Dimensions (W x H x D)
    1926.6 X 1098 X 60
    Carton Dimensions (W x H x D)
    2080 X 220 X 1255
  • VESA™ Standard Mount Interface
    600 x 400
HW FEATURE
  • Internal Memory (eMMC)
    8GB
    Wi-Fi/BT (Built-in)
    Yes
  • Temperature Sensor
    Yes
    Auto Brightness sensor
    Yes
  • Acceleration(Gyro) Sensor
    Yes
    Local Key Operation
    Yes (Power On/Off only)
SW FEATURE
  • OS Ver. (webOS)
    webOS6.1
    Local Contents Scheduling
    Yes
  • Group Manager
    Yes
    USB Plug & Play
    Yes
  • Fail over
    Yes
    Booting Logo Image
    Yes
  • No Signal Image
    Yes
    RS232C Sync
    Yes
  • Local Network Sync
    Yes
    Screen Share
    Yes
  • Video Tag
    Yes(4, Max One HDMI input)
    Play via URL
    Yes
  • Screen Rotation
    Yes
    External Input Rotation
    Yes
  • Gapless Playback
    Yes
    Tile Mode Setting
    Yes
  • Setting Data Cloning
    Yes
    SNMP
    Yes
  • ISM Method
    Yes
    Auto Set ID
    Yes
  • Status Mailing
    Yes
    Control Manager
    Yes
  • Cisco Certification
    Yes(TBD)
    Crestron Connected
    Yes
  • Smart Energy Saving
    Yes
    PM mode
    Yes
  • Wake on LAN
    Yes
    Network Ready
    Yes
  • Beacon
    Yes
    HDMI-CEC
    Yes
  • SI Server Setting
    Yes
    webRTC
    Yes
  • Pro:Idiom
    Yes
ENVIRONMENT CONDITIONS
  • Operation Temperature
    0 °C to 40 °C (Portrait Scene : 0 °C to 35 °C)
    Operation Humidity
    10 % to 80 %
POWER
  • Power Supply
    AC 100-240V~, 50/60Hz
    Power Type
    Built-In Power
POWER CONSUMPTION
  • Typ.
    205 W
    Max.
    287 W
  • BTU (British Thermal Unit)
    699.489BTU/Hr(Typ.), 979.284BTU/Hr(Max.)
    Smart Enegy Saving (70%)
    143.5W
  • DPM
    0.5 W
    Power off
    0.5 W
SOUND
  • Speaker (Built-in)
    Yes (10W X 2)
CERTIFICATION
  • Safety
    CB
    EMC
    FCC Class "B" / CE
  • ErP / Energy Star
    NA(New ERP)/Yes
    ePEAT(US only)
    Yes
SOFTWARE COMPATIBILITY
  • SuperSign CMS
    Yes
    SuperSign Control+
    Yes
  • SuperSign WB
    Yes
    SuperSign Cloud
    Yes
  • Mobile CMS
    Yes
    Connected Care
    Yes
Language
  • OSD
    English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic, polski
ACCESSORY
  • Basic
    Remote Controller(include battery 2ea), Power Cord, Regulation Book, Easy setup guide, Warranty Card, Phone to D-Sub9 Gender
SPECIAL FEATURE
  • Conformal Coating (Power Board)
    Yes
COMPLIANCE INFORMATION
  • The safety information for accessories is included with the safety information for the product and is not provided separately.

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
