With a great brightness of 3,000 cd/㎡, XF series clearly deliver contents and attract public attention, which is the ultimate display for outdoor visibility.
Visible with Polarized Sunglasses
QWP* enables clear visibility even when the viewer is wearing polarized sunglasses.
Even under direct sunlight exposure, the open frame XF series remain free of blackening defects under 110°C and provide superior quality for outdoor usage.
Smart Brightness Control
The auto brightness sensor and preset time scheduler save power consumption by adjusting the brightness.
High Operating Temperature
Its high reliability under high operating temperatures reduces additional costs for air conditioning system.
The conformal coating enhances circuit board reliability by protecting it from dust, iron shavings, humidity and other harsh conditions.
High-Performance with webOS
Quad Core SoC* can execute several tasks at the same time without a separate media player. In addition, webOS 3.0 platform enhances user convenience with intuitive UI and simple app develoment tools.
|Resolution||3,840 x 2,160 (UHD)|
|Brightness (Typ., cd/m²)||3000|
|Input||HDMI(2), DP, DVI-D, Audio, USB, SD Card|
|Output||DP, External Speaker Out (L/R)|
|External Control||RS232C In/Out, RJ45 In, IR Receiver In, Pixel Sensor In|
|Bezel Width||12.8 mm(Even bezel)|
|Monitor Dimension (W x H x D)||1,675.2 x 953.6 x 123.9 mm|
|Weight (Head)||36.7 kg|
|Carton Dimensions (W x H x D)||1,816 x 1,106 x 285 mm|
|Packed Weight||46.3 kg|
|Operation Temperature||0°C to 50°C (w/o Direct Sunlight) / 0°C to 40°C (Direct Sunlight)|
|Operation Humidity||10% to 85%|
|Power Supply||100-240V~, 50/60Hz|
|Power Type||Built-In Power|
|Typ./Max||660W / 695W|
|Smart Energy Saving||320W|
|Safety||UL recognized / CB|
|EMC||FCC Class "A" / CE / KC / VCCI|
|Content Management Software||SuperSign CMS|
|Control and Monitoring Software||SuperSign C|
|Basic||Remote Controller (2 Batteries Included), Power Cord, IR Extension Cable/PCB, HDMI Cable, Manual (ESG & EIG)|
|Optional||Pixel Sensor (KT-SP0)
* Stand is not available
