Floor LED Display for Virtual Production
Inquiry to Buy

Floor LED Display
for Virtual Production

A virtual production studio with curved LED walls and ceiling and floor LEDs is filming a video of snowy mountain scenery. A virtual production studio with curved LED walls and ceiling and floor LEDs is filming a video of snowy mountain scenery.
* All images in this page are for illustrative purposes only.
This demonstrates that the LEDs can withstand the weight of a vehicle on them and still work well. This demonstrates that the LEDs can withstand the weight of a vehicle on them and still work well.

High Durability

LFCL series is a unique display installed on the floor with high durability designed to load up to 1,500 kg/sqm.
LFCL is developed with a matte, anti-slip surface with IP66 protection. LFCL is developed with a matte, anti-slip surface with IP66 protection.

Excellent Usability

Surface safety when installing the screen on the floor (IP66 protective non-slip mat) and high visual performance (with high contrast LED for uniform visual performance in black) are considered.

* As the surface is made of polycarbonate, it may be susceptible to scratches (especially against metal).

Easy Installation and Maintenance

Its simple product structure allows for easy installation and quick maintenance. You can quickly deploy and connect the cabinets with the foot support system without any tools. A simple flush control mechanism design is applied to keep the height level regardless of floor type. In addition, magnets attached to the LED module allow for easy maintenance, and hot-swapping* is able during the display operation.
It is easy to install LFCL by simply fixing the cabinet with the footer, and the magnets attached to the LED module allow for easy maintenance with the screen on. It is easy to install LFCL by simply fixing the cabinet with the footer, and the magnets attached to the LED module allow for easy maintenance with the screen on.
* Hot Swapping : Swap module on-site during screen’s on the operation.
A bright-screen floor LED is installed in a studio. A bright-screen floor LED is installed in a studio.

High Brightness

The LFCL series gives a versatile filming experience in XR Stage and mid-sized VP Studio. Moreover, the rendered content is highly visible with 3,000 nits. Available to shoot dust and water scenes with IP66 rating. The realistic filming of desert, beach, and fire scenes keep DP and camera operators contented.
A virtual production studio which has curved LED walls and ceiling and floor LEDs is being filmed, and a compatible controller is being displayed next to it. A virtual production studio which has curved LED walls and ceiling and floor LEDs is being filmed, and a compatible controller is being displayed next to it.

Brompton LED Processor & Data Distribution

As Brompton controllers are common in the broadcast and virtual production industry, LFCL series offers support for them.
Close
Physical Parameters
  • Pixel Configuration
    3 in 1 SMD
    Pixel Pitch(mm)
    3.906
  • Module Resolution (WxH)
    64x64
    Module Dimensions(WxH,mm)
    250x250
  • Weight per Module (kg)
    0.90
    No. of Modules per Cabinet (WxH)
    2 x 2
  • Cabinet Resolution (WxH)
    128 x 128
    Cabinet Dimensions (W x H x D, mm)
    500x500x84.5
  • Cabinet Surface Area (㎡)
    0.250
    Weight per Cabinet (kg/unit)
    10.5
  • Weight per Square Meter (kg/m²)
    42.0
    Physical Pixel Density (pixels/m²)
    65,536
  • Flatness of Cabinet (mm)
    ±0.5
    Cabinet Material
    Die-casting Aluminum
  • Service Access
    Front
OPTICAL SPECIFICATIONS
  • Max Brightness (After Calibration, nit)
    3,000
    Color Temperature (K)
    2,000-11,000
  • Visual Viewing Angle (Horizontal)
    120
    Visual Viewing Angle (Vertical)
    120
  • Brightness Uniformity
    ≥97%
    Color Uniformity
    ±0.003Cx,Cy
  • Contrast Ratio
    5,000:1
    Processing Depth (bit)
    14 (PQ, HLG)
ELECTRICAL SPECIFICATIONS
  • Power Consumption (W/Cabinet, Max.)
    240
    Power Consumption (W/Cabinet, Avg.)
    80
  • Power Consumption (W/m², Max.)
    960
    Heat Dissipation (BTU/h/Cabinet, Max.)
    819
  • Heat Dissipation (BTU/h/Cabinet, Avg.)
    273
    Heat Dissipation (BTU/h/m², Max.)
    3,276
  • Power Supply (V)
    100 to 240
    Frame Rate (Hz)
    50 / 60
  • Refresh Rate (Hz)
    3,840
OPERATION SPECIFICATIONS
  • LED Lifetime (Half brightness)
    100,000
    Operating Temperature(℃)
    -10℃ to +45℃
  • Operating Humidity
    0-80%RH Non-condensing
    IP Rating Front
    IP65
  • IP Rating Rear
    IP65
Certification
  • Certification
    CE,FCC,ETL
Controller
  • Controller
    Brompton SX40
Series
  • Series
    LFCL
  • Dimension
    • LFCL039-GN-v1.0.dwg
    • LFCL039-GN-v1.0.pdf
  • Datasheet
    • LFCL-Series_Datasheet(low)_LG-Indoor-LED_220711.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
