32LX320C (EU-over32) component-copyModelName
LX320C Series

Key Features

component-OBScountrySelectDesc

LX320C Series
LCD Panel Specification
  • Backlight Type
    LED (Slim Direct L)
    Cinema 3D
    -
  • Resolution
    1,366 X 768 (HD)
    Brightness (cd/m²l, Typ)
    300
Broadcasting System
  • Analog
    PAL/SECAM
    Terrestrial
    DVB-T
  • Cable
    DVB-C
    Satellite
    -
Video
  • Real Cinema 24p (3:3 Pull down)
    Yes
    Aspect Ratio
    8 modes (16:9, Just Scan, Original, Full wide, 4:3, 14:9, Zoom, Cinema Zoom 1)
Audio
  • Audio Output
    10W + 10W
    Wireless Sound Sync
    -
Feature
  • Pro:Centric
    -
    Pro:Idiom
    -
Interface - Set Side
  • Headphone Out
    1
    RF In
    -
  • AV In
    -
    S-Video In
    -
  • RGB In (D-sub 15pin)
    -
    Component in (Y,Pb,Pr)
    -
  • PC Audio Input
    -
    HDMI In
    1
  • USB (2.0)
    1 (2.0)
    CI Slot
    1
  • IR Out
    -
Interface - Set Rear
  • RF In
    1
    AV In
    -
  • AV Out
    -
    S-Video In
    -
  • Full Scart
    1
    Component in (Y,Pb,Pr-Video)
    1 (Phone Jack)
  • Component in (Audio)
    1 (Phone jack):Component/DVI/PC Audio
    Digital Audio Out (Coaxial / Optical)
    1 (Optical)
  • HDMI/HDCP Input
    1
    USB 2.0
    -
  • RGB In (D-sub 15pin) - PC
    1
    PC Audio Input
    1 (Phone Jack, Component)
  • RS-232C (D-sub 9pin)
    1
    Headphone Out
    -
  • Clock Interface
    -
    LAN Port
    -
  • RJ45 (RJP interface)
    -
    External Speaker Out(3.5mm phone jack)
    1 (Spk-out 1)
  • TV link Configuration (phone jack type)
    -
Power
  • Voltage, Hz
    100 ~ 240V, 50/60Hz
    Typical (Watts)
    56.8W
Tool Description
  • Swivel (angle)
    -
    VESA Compatibility
    200 X 200
Required Listing(Certification)
  • Safety
    CB
    EMC
    CE
  • ETC.
    ROHS, ErP, Eco flower
Dimension
  • WxHxD (w/o stand, mm)
    732 X 437 X 55.5
    WxHxD (with stand, mm)
    732 X 481 X 207
General
  • Region
    Europe
  • Dimension
    • [Drawing] 32LB56_LX320C_EU_MEA.dwg
    • [Drawing] 42LB56_LX320C_EU_MEA.dwg
    • [Drawing] 32LB56_LX320C_EU_MEA.pdf
    • [Drawing] 42LB56_LX320C_EU_MEA.pdf
  • Datasheet
    • [Leaflet] Final_LX320C_EU.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
