Interactive Digital Board
Contact Us

Core Features,
Powerful Performance with

A large interactive digital board is mounted on the meeting room wall, mirroring the meeting content displayed on a laptop screen placed on the table. A large interactive digital board is mounted on the meeting room wall, mirroring the meeting content displayed on a laptop screen placed on the table.
* All images in this page are for illustrative purposes only.

Seamless Writing Experience

LG CreateBoard delivers a lifelike touch experience with support for 4K resolution, enabling users to write seamlessly, ensuring every detail is crisp and clear.
In a studio workspace, a group collaborates by writing directly onto a large wall-mounted smart whiteboard during a discussion. In a studio workspace, a group collaborates by writing directly onto a large wall-mounted smart whiteboard during a discussion.

Multi-Touch

LG CreateBoard boasts a multi-touch functionality that can concurrently detect up to 40 touch points. This feature facilitates simultaneous touch and gesture inputs from multiple users, fostering easy collaboration and idea sharing among team members. This enables efficient interaction in group activities or meetings.
Students are actively exchanging ideas by writing on LG’s interactive digital board screen at the same time. Students are actively exchanging ideas by writing on LG’s interactive digital board screen at the same time.

Connect Your Own Device for OS Flexibility

LG CreateBoard integrates smoothly with devices across various operating systems, including Windows, Android, and ChromeOS, allowing users to work within their preferred environments. This creates a flexible and highly adaptable workspace tailored to individual needs.
The TR3BQ can be connected to various devices such as laptops, Chromebooks, and Windows or Chrome OPS, allowing users to operate their preferred OS directly on the digital board. The TR3BQ can be connected to various devices such as laptops, Chromebooks, and Windows or Chrome OPS, allowing users to operate their preferred OS directly on the digital board.

C-Type Connection

USB-C connectivity simplifies connections which enables charging and sending data simultaneously over just one single cable.
USB-C connectivity simplifies connections, easily enables screen sharing and audio output, and can charge devices with up to 65W. USB-C connectivity simplifies connections, easily enables screen sharing and audio output, and can charge devices with up to 65W.
* USB Type-C cables are sold separately.

OTA (Over-The-Air) Functionality

OTA (Over-The-Air) functionality built into the LG CreateBoard enables software updates to be performed wirelessly and automatically, allowing users to maintain the latest features and security patches.
An digital smart board is performing a wireless automatic software update. An digital smart board is performing a wireless automatic software update.
The LG smart board has front ports such as USB and HDMI. The LG smart board has front ports such as USB and HDMI.

Front Connectivity Design

LG CreateBoard is designed with front display ports, making it easy for users to connect or disconnect cables.

* Some ports including the power connector, are located on the side and back of the unit.
The built-in OPS slot makes OPS installation easy, providing users with extended functionality such as various PC features and Windows software without needing an external desktop. The built-in OPS slot makes OPS installation easy, providing users with extended functionality such as various PC features and Windows software without needing an external desktop.

Built-In OPS Slot

LG CreateBoard supports OPS slots, allowing users to conveniently mount OPS Module at the back of the screen without the hassle of connecting to an external desktop. This enables various PC functions and Windows software.

* OPS : Open Pluggable Specification
* OPS slot is sold separately.
Close
Info
  • Product
    Touch
    Year
    Y25
  • Month
    M05
Panel
  • Screen Size (Inch)
    65"
    Panel Technology
    VA
  • Back Light Type
    Direct
    Aspect Ratio
    16:9
  • Native Resolution
    3840x2160 (UHD)
    Refresh Rate
    60Hz
  • Brightness
    350nit (Typ.)
    Contrast Ratio
    5000:1
  • Dynamic CR
    5000:1
    Color gamut
    NTSC 72%
  • Viewing Angle (H x V)
    178 x 178
    Color Depth (Number of Colors)
    10bit(8bit + FRC)
  • Response Time
    6.5ms
    Surface Treatment (Haze)
    25%
  • Life time
    50,000 Hrs (Min.)
    Operation Hours (Hours/Day)
    16/7
  • Portait / Landscape
    No / Yes
Connectivity(Jack Interface)
  • HDMI IN
    Yes(3)
    Audio IN
    Yes(1)
  • RS232C IN
    Yes(1)
    RJ45(LAN) IN
    Yes(1)
  • USB IN
    USB3.0 Type A(4). USB2.0 Type A(1), USB Type-C(1)
    Audio Out
    Yes(1), Optical Yes(1, SPDIF)
  • Touch USB
    Yes(2)
    RJ45(LAN) Out
    Yes(1)
Mechanical
  • Bezel Color
    Black
    Bezel Width
    T/R/L/B：16.6/16.6/16.6/45mm
  • Weight (Head)
    32.1Kg
    Packed Weight
    (TBD)
  • Monitor Dimensions (W x H x D)
    1491 × 899 × 98mm
    Carton Dimensions (W x H x D)
    1628 × 1014 × 185mm
  • Handle
    Yes(2)
    VESATM Standard Mount Interface
    600x400mm
Protection Glass
  • Thickness
    3.2mm
    Degree of Protection
    Safety Glass
  • Tempered / Chemical strengthening
    Tempered strengthening
    Anti-Reflective
    Yes
  • Shatter-Proof
    Yes
HW Feature
  • Auto Brightness sensor
    Yes
    Power Indicator
    Yes
  • Local Key Operation
    Yes
SW Feature
  • RS232C Sync
    Yes (LG RS232C Command)
    Screen Share
    Yes (CreateBoard Share)
  • Smart Energy Saving
    Yes (Energy Saving)
    Wake on LAN
    Yes
  • HDMI-CEC
    Yes
Environment Conditions
  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10% to 90%
Power
  • Power Supply
    AC 100-240V~, 50/60Hz
    Power Type
    Built-In Power
Power Consumption
  • Typ.
    127W
    Max.
    360W
  • BTU (British Thermal Unit)
    433 BTU/Hr(Typ.), 1228 BTU/Hr(Max)
    Smart Enegy Saving (70%)
    Yes
  • DPM
    0.5W
    Power off
    0.5W
Sound
  • Speaker (Built-in)
    Yes (16Wx2)
Certification
  • Safety
    CB / NRTL
    EMC
    FCC Class "A" / CE / KC
  • ErP / Energy Star
    Yes / No
OPS Compatibility
  • OPS Type Compatible
    Yes (Slot)
    OPS Power Built-in
    Yes
Language
  • OSD
    English, Simplified Chinese, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Russian, Spanish, Swedish, Türkçe, Ukrainian, Traditional Chinese, Hungarian, Thai, Indonesian, Kazakh, Catalan, Basque, Japanese, Estonian, Lithunian
Accessory
  • Basic
    (TBD)
    Optional
    Wall Mount(WM-L000S), Floor Stand(ST-000F, ST860F)
Special Feature
  • Conformal Coating (Power Board)
    Yes
    Power protection
    Yes
Touch
  • Available object size for touch
    Ø3 mm ↑
    Response Time
    ≤10ms
  • Writing Height
    ≤2mm
    Accuracy (Typ.)
    ±1.5mm
  • Interface
    USB2.0
    Protection Glass Thickness
    3.2mm (Anti-Glare)
  • Protection Glass Transmission
    88%
    Operating System Support
    Windows10/Windows8/Windows7/Android/Linux/macOS/Chrome
  • Multi touch point
    Max 40 points
Create Board
  • LAN
    Gigabit LAN
