LAP025E
P2.5 1,000 nits LG LED Curve Series for Indoor
  • Pixel Pitch: 2.5 mm
  • Brightness: 1,000 cd/m²
  • Modular design
  • Curvature(Concave/convex): Up to 1,000R
  • High performance system controller
  • Front and rear serviceability

component-OBScountrySelectDesc

P2.5 1,000 nits LG LED Curve Series for Indoor

Physical Parameters

  • Pitch Name
    P2.5
    Pixel Configuration
    3 in 1 SMD
  • Pixel Pitch (mm)
    2.50
    Module Resolution (W x H)
    96 x 72
  • Module Dimensions (W x H, mm)
    240 x 180
    Weight per Module (kg)
    0.36
  • No. of Modules per Unit Frame (W x H)
    2 x 3
    Unit Case Resolution (W x H)
    192 x 216
  • Unit Case Dimensions (W x H x D, mm)
    480 x 540 x 53
    Unit Case Surface Area (m²)
    0.260
  • Weight per Unit Case (kg/unit)
    6.0
    Weight per Square Meter (kg/m²)
    21.3
  • Physical Pixel Density (pixels/m²)
    160,000
    Flatness of Unit Case (mm)
    ±0.2
  • Unit Case Material
    Die Casting Aluminum
    Service Access
    Front and Rear

Optical Parameter

  • Min. Brightness (After Calibration)
    1,0001) cd/m²
    1)Brightness can be reduced (up to 300nit) by the number of PSU modules, thereby decreasing power consumption.
    Color Temperature
    3,200 ~ 9,300
  • Visual Viewing Angle (Horizontal)
    160
    Visual Viewing Angle (Vertical)
    140
  • Brightness Uniformity
    95%
    Color Uniformity
    ±0.015Cx, Cy
  • Contrast Ratio
    6,000
    Processing Depth (bit)
    16 (HDR10)

Electrical Parameter

  • Power Consumption (W/Unit, Max.)
    143
    Power Consumption (W/Unit, Avg.)
    52
  • Power Consumption (W/m², Max.)
    550
    Heat Dissipation (BTU/h/Cabinet, Max.)
    488
  • Heat Dissipation (BTU/h/Cabinet, Avg.)
    177
    Heat Dissipation (BTU/h/m², Max.)
    1,876
  • Power Supply (V)
    100 to 240
    Frame Rate (Hz)
    50 / 60
  • Refresh Rate (Hz)
    3,840

Operation Conditions

  • Lifetime (Hours to Half Brightness)
    50,000
    Operating Temperature (°C)
    0°C to + 40°C
  • Operating Humidity
    10-80% RH

Certification

  • EMC
    FCC Class A / CE / KC
    Environment
    RoHS

Controller

  • Controller
    LCLG003-B

Connectivity

  • Video Inputs
    HDMI In, DP In, OPS In, USB
    Control
    RJ45 In, RS232C In/out
  • Special Features
    HDR10, Temperature Sensor, Power Detection, ADA Compliant, PSU Hot Swappable
  • Dimension
    • (Dimension) LAPE_LDM.dwg
    • (Dimension) LED controller_LLLG003-D.dwg
    • (Dimension) Power supply unit_LPLG001.dwg
    • (Dimension) System controller_LCLG003-D.dwg
    • (Dimension) Unit frame_LFLG000E.dwg
    • (Dimension) LAPE_LDM.pdf
    • (Dimension) LED controller_LLLG003-D.pdf
    • (Dimension) Power supply unit_LPLG001.pdf
    • (Dimension) System controller_LCLG003-D.pdf
    • (Dimension) Unit frame_LFLG000E.pdf
  • Datasheet
    • LG Real Curve LED_LAPE series_Datasheet(web)_2008.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
