Outdoor LED Display for Cruise Ships
Inquiry to Buy

Outdoor LED Display for
Cruise Ships

People are enjoying swimming in the cruise’s pool, and a large LED is hanging on the walls on board. The LED screen is promoting the cruise’s Summer Night Party that will be held on the cruise. People are enjoying swimming in the cruise’s pool, and a large LED is hanging on the walls on board. The LED screen is promoting the cruise’s Summer Night Party that will be held on the cruise.
* All images in this page are for illustrative purposes only.
GNEB series has Conformal Coating on the power board to protect LED even in a humid or salty environment. GNEB series has Conformal Coating on the power board to protect LED even in a humid or salty environment.

Durability for Rough Environment

GNEB series provides durability with marine-grade powder coating and conformal coating to protect against salinity and corrosion in marine environments and weather conditions. Both the front and rear of the cabinet are IP67-certified and feature reliable designs for seaside, allowing for stable power and data connections protected by outdoor environmental factors such as wet weather and the salinity. The unexposed front screws further lower the risk of corrosion.

* Metal parts meet Qualicoat standards.
GNEB series can offer front and rear access, and get easy replacement with handles. GNEB series can offer front and rear access, and get easy replacement with handles.

Easy Maintenanace

The product offers both front and rear access, and features a power distribution unit (PDU) of a modular cabinet that can be easily attached or detached, thereby allowing for easy maintenance. A self-contained PSU and receiver card with handles allow quick and easy replacement.
There is a LED screen and the screen is being watched with two mobile phone cameras. Despite showing the same advertisement, the conventional screen shows black bars, but the GNEB series clearly shows the original screen. There is a LED screen and the screen is being watched with two mobile phone cameras. Despite showing the same advertisement, the conventional screen shows black bars, but the GNEB series clearly shows the original screen.

High Refresh Rate

A high refresh rate of 7,680 Hz assures the smooth playback of content. The flicker-free image prevents the black bars that typically occur during video playback, and reduces eye strain and blurred images for viewers.
It shows different sizes of LEDs, such as 1600 by 1200, 1600 by 1800, 800 by 1200, and 3200 by 3600. It shows different sizes of LEDs, such as 1600 by 1200, 1600 by 1800, 800 by 1200, and 3200 by 3600.

Flexible Configuration and Installation

A variety of cabinet sizes are supported for flexible screen configuration and installation. Sizes of up to a 3,200 × 3,600 mm super cabinet are available for more convenient installation.

Compatibility with LG Software Solutions

When connected with LG's CVEA system controller, the GNEB series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
"The LG employee is remotely monitoring the GNEB series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables GNEB series to be compatible with LG software solutions." "The LG employee is remotely monitoring the GNEB series installed in a different place by using a cloud-based LG monitoring solution. System controller with webOS enables GNEB series to be compatible with LG software solutions."
* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
* The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
* Actual GUI may vary in different webOS versions.
* SuperSign CMS service needs to be purchased separately.
Close
Physical Parameters
  • Pitch Name
    P6.25
    Pixel Configuration
    Single SMD
  • Pixel Pitch(mm)
    6.25
    Module Resolution (WxH)
    64x96
  • Module Dimensions(WxH,mm)
    400x600
    Weight per Module (kg)
    8.33
  • Weight per Square Meter (kg/m²)
    34.7
    Physical Pixel Density (pixels/m²)
    25,600
  • Flatness of Cabinet (mm)
    ±1.0
    Cabinet Material
    Al
  • Service Access
    Front or Rear (select one only)
OPTICAL SPECIFICATIONS
  • Max Brightness (After Calibration, nit)
    6,000
    Color Temperature (K)
    3,500~8,500
  • Visual Viewing Angle (Horizontal)
    140
    Visual Viewing Angle (Vertical)
    130
  • Brightness Uniformity
    97%
    Color Uniformity
    ±0.05Cx,Cy
  • Contrast Ratio
    5,000:1
    Processing Depth (bit)
    16 (HDR10, HDR10 Pro)
ELECTRICAL SPECIFICATIONS
  • Power Consumption (W/Cabinet, Max.)
    167
    Power Consumption (W/Cabinet, Avg.)
    67
  • Power Consumption (W/m², Max.)
    696
    Heat Dissipation (BTU/h/Cabinet, Max.)
    569
  • Heat Dissipation (BTU/h/Cabinet, Avg.)
    228
    Heat Dissipation (BTU/h/m², Max.)
    2,367
  • Power Supply (V)
    100 to 240
    Frame Rate (Hz)
    50 / 60
  • Refresh Rate (Hz)
    7,680
OPERATION SPECIFICATIONS
  • LED Lifetime (Half brightness)
    100,000
    Operating Temperature(℃)
    -30°C to +50°C
  • Operating Humidity
    0~90%RH
    IP Rating Front
    IP67
  • IP Rating Rear
    IP67
Certification
  • Certification
    CE, FCC, ETL
Environment
  • Environment
    RoHS, REACH
Controller
  • Controller
    CVEA
90 Degree Corner Cut
  • 90 Degree Corner Cut
    Yes
Series
  • Series
    GNEB
  • Dimension
    • GNEB0xx-GN 2x2 Cabinet-v1.0 (1).dwg
    • GNEB0xx-GN-v1.0 (1).dwg
    • GNEB0xx-GN 2x2 Cabinet-v1.0.pdf
    • GNEB0xx-GN_3D-v1.0.zip
  • Datasheet
    • GNEB-Series_Datasheet(low)_LG-Outdoor-LED_220801.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
