14,000 BTU Heat/Cool Portable Air Conditioner with Remote

  • LP1413SHR

Key Features

  • Dehumidification Function
  • Oscillating Air Vent
  • Heat Pump Technology
  • Programmable 24-hour on-off timer
PERFORMANCE
EER 10.1
Dehumid. (Pts/Hr) 3.4
Dry Air Flow (CFM) 270
Est. Cooling Area (Sq. Ft.) 600
BTU Performance Cooling 14,000
BTU Performance Heating 14,000
COP 10.1
DIMENSIONS
Product (WxHxD) 18 1/2" x 33 1/16" x 13"
Shipping (WxHxD) 23 1/8" x 34 7/16" x 17 1/2"
Net Weight (lbs.) 72.8
Shipping Weight (lbs.) 81.6
FEATURES
Display Panel White LCD
Thermostat Control Yes
Remote Control LCD Remote Controller
Auto Swing Yes
Energy Saver Function Yes
Programmable Timer 24Hr, On/Off
Fan Speed: Cooling 3
Fan Only Speed 3
Compressor LVN
Type Air Discharge Inclined and Top
Outdoor Vent / Exhaust Exhaust Only (1.5M)
Chassis Type Fixed
Control Button Type Digital touch sensor
Auto Restart Yes
Auto Door Open/Close System Yes
Indoor / Outdoor Fan Type Blower
Water Full Indicator Yes
MATERIALS/FINISHES
Available Colors Silver
Easy-Roll Casters Yes
Air Filter Washable
Window Installation Kit Yes
ELECTRICAL RATINGS
Voltage / 60 Hz 115
Watts 1,380
Rated Amps 12.0

What People Are Saying

  • bvseo_sdk, java_sdk, bvseo-2.3.0.0
  • CLOUD, getReviews, 367ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

We're here to support you with our product.

View LP1413SHR Product Support

Contact us for any support inquiries.

ASK & ANSWER

Ask your questions. Share your answers.
Please first review the detailed product information and help guides in the Product Support section for this product prior to posting a question.

Is there a way to drain the lower tank by using the upper drain hose? I am having to empty the lower tank about every 16 hours. It's very inconvenient and I'm thinking about returning this unit bc of this. I have to unhook it and take it outside for this.

Asked by: Jacobhon66
If we have understood your inquiry correctly, the end point of the drain pipe that fits into the upper drain port on the LG 14,000 BTU Heat/Cool Portable Air Conditioner with Remote, Model # LP1413SHR will not fit into the lower drain port. If you are looking to attach a drain hose to the bottom drain port, you will need to purchase a drain hose that has an inner diameter of 18 mm (11/16") that is long enough for you to either place it's open end in a suitable drain location or to drain it to the outside. You will want to check your local Home improvement stores to see if they are carrying such a hose...^IFV
Answered by: LGJoel
Date published: 2016-07-19

I have my ac on this summer and the air conditioner seems to be leaking profusely. It has been in the 80 and 90 lately and I have a 2 month old son. I tried draining the lower portion on the unit but it still continues to leak how do I fix this situation

Asked by: Coolnova4
We regret the trouble you have experienced with this air conditioner. Has this been a matter of the tank filling to the point of deactivating or actually leaking water? Please contact our Customer Interactive Center at 800-243-0000.
Answered by: NeilE
Date published: 2016-07-18

In heat mode the unit needs to be drained every few hours from the bottom reservoir. This is cumbersome to say the least. The upper drain is for what purpose?  It seems to drain nowhere?

Asked by: Davisbuilt
The purposes for both drains and how to use them on your LG 14,000 BTU Heat/Cool Portable Air Conditioner with Remote, Model # LP1413SHR are fully explained on pages 22 and 25 of your owner's manual. The Bottom drain is used for draining water when you are using the heating function and the Upper drain is used for emptying the internal Water Collection Tank when it gets full and your display shows "FL" to indicate that it is full and needs to be emptied...^IFV
Answered by: LGJoel
Date published: 2015-11-19

Is there a way to tell if the pump is on in heat mode, other than watching water flow through the tube?  (a light or flash or something?)

Asked by: Davisbuilt
Other than seeing a confirmation on the display panel of the LG 14,000 BTU Heat/Cool Portable Air Conditioner with Remote, Model # LP1413SHR when you change it to the HEAT mode and the temperature reflected on the display, there is no way to tell if it is on...^IFV
Answered by: LGJoel
Date published: 2015-11-19

The FL code keeps coming on, I just emptied the tank there was only about 5 Oz of water in the tank. What does this mean.

Asked by: James1717
We regret the trouble you have experienced with this air conditioner. If the FULL TANK indicator continues to display, which drain port is being opened: that which is by the exhaust duct, or that which is at the bottom of the casing. The FL code should indicate the need for draining the LOWER drain port. If this does not resolve the matter, then the unit may require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2015-08-14

FL Code - draining the water

I always have a drain pipe installed on the upper drain port, either feeding into a bucket or the outside, depending on the outside temperature. When I get the FL code meaning the water tank is full, do I need to drain from the upper or lower drain port, or both? I thought the upper port would drain on its own when needed if a drain pipe is constantly installed. The manual gives instructions for both ports but does not tell you the difference or which one you should drain when getting the FL code. I do use the HEAT mode a good bit.
Asked by: LindaLu64
We appreciate your interest in this portable air conditioner. If a drain pipe is constantly attached to the upper drain port, and the FL code appears, it is recommended to try draining the lower drain port.
Answered by: NeilE
Date published: 2015-01-29

the heat is not working it blowing out cold air in the heat mode

Asked by: fatgirl
We regret the trouble you have experienced with this air conditioner unit. Please contact our Customer Interactive Center at 800-243-0000 that we might properly troubleshoot this matter with you.
Answered by: NeilE
Date published: 2014-12-17

My LG LP 1413SHR says its needs drained and its new

Theres no water in it and it flashes FL, what is the issue? thanks
Asked by: Fatref09
We regret the trouble you have experienced with this air conditioner. If there is no water in the reservoir, and it is reading full, then there may be a problem with the moisture sensor of the product. The unit will likely require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2014-11-05
