Model Name | LBS062DA1-V | LBS062DA3-V | LBS083DA1-V | LBS083DA3-V |
---|---|---|---|---|
Pixel Configuration | 3 in 1 SMD | 3 in 1 SMD | 3 in 1 SMD | 3 in 1 SMD |
Pixel Pitch(mm) | 6.25 | 6.25 | 8.33 | 8.33 |
Unit Case Resolution (WxH) |
128x256 | 128x256 | 96x192 | 96x192 |
Unit Case Dimensions (WxHxD, mm) |
800x1600x143.5 | 800x1600x143.5 | 800x1600x143.5 | 800x1600x143.5 |
Weight per Unit Case / Square Meter (kg) |
40.0/31.3 | 40.0/31.3 | 40.0/31.3 | 40.0/31.3 |
Service access | Front and Rear | Front and Rear | Front and Rear | Front and Rear |
Min. Brightness (After Calibration) |
6,000 | 6,000 | 6,000 | 6,000 |
Color Temperature | 3500-8500 | 3500-8500 | 3500-8500 | 3500-8500 |
Visual Viewing Angle (Horizontal/Vertical) |
160/130 | 160/130 | 160/125 | 160/125 |
Brightness Uniformity / Color Uniformity | ±0.05Cx,Cy | ≥97%/±0.05Cx,Cy | ≥97%/±0.05Cx,Cy | ≥97%/±0.05Cx,Cy |
Contrast Ratio | 3,000 | 3,000 | 3,000 | 3,000 |
Processing Depth (bit) | 16 | 16 | 16 | 16 |
Power Consumption (W/Unit, Avg./Max.) |
312/780 | 312/780 | 320/800 | 320/800 |
Power Consumption (W/m², Max.) |
609 | 609 | 625 | 625 |
Power Supply (V) | 100 to 240 | 100 to 240 | 100 to 240 | 100 to 240 |
Refresh Rate (Hz) | 4,000 | 4,000 | 4,000 | 4,000 |
Lifetime (Half brightness)* |
100,000 | 100,000 | 100,000 | 100,000 |
Operating Temperature(°C) / Humidity | -20° to +50°/< 90%RH | -20° to +50°/< 90%RH | -20° to +50°/< 90%RH | -20° to +50°/< 90%RH |
IP rating Front / Rear | IP66/IP66 | IP66/IP66 | IP66/IP66 | IP66/IP66 |
Model Name | LBS100DA1-V | LBS100DA3-V |
---|---|---|
Pixel Configuration | 3 in 1 SMD | 3 in 1 SMD |
Pixel Pitch(mm) | 10.00 | 10.00 |
Unit Case Resolution (WxH) |
80x160 | 80x160 |
Unit Case Dimensions (WxHxD, mm) |
800x1600x143.5 | 800x1600x143.5 |
Weight per Unit Case / Square Meter (kg) |
40.0/31.3 | 40.0/31.3 |
Service access | Front and Rear | Front and Rear |
Min. Brightness (After Calibration) |
6,000 | 6,000 |
Color Temperature | 3500-8500 | 3500-8500 |
Visual Viewing Angle (Horizontal/Vertical) |
160/115 | 160/115 |
Brightness Uniformity / Color Uniformity | ≥97%/±0.05Cx,Cy | ≥97%/±0.05Cx,Cy |
Contrast Ratio | 3,000 | 3,000 |
Processing Depth (bit) | 16 | 16 |
Power Consumption (W/Unit, Avg./Max.) |
300/750 | 300/750 |
Power Consumption (W/m², Max.) |
586 | 586 |
Power Supply (V) | 100 to 240 | 100 to 240 |
Refresh Rate (Hz) | 4,000 | 4,000 |
Lifetime (Half brightness)* |
100,000 | 100,000 |
Operating Temperature(°C) / Humidity | -20° to +50°/< 90%RH | -20° to +50°/< 90%RH |
IP rating Front / Rear | IP66/IP66 | IP66/IP66 |
