Discontinued
DH3140S
LG 300W DVD Home Theater System
  • 5.1channel
  • 300W
  • Portable IN
  • Karaoke

component-OBScountrySelectDesc

LG 300W DVD Home Theater System

MAIN SPECS

  • Power Out Put / Channel
    300 Watts, 5.1 Ch DVD Home Theater
    Front L/R
    45WX2
  • Center
    45W
    Sub-woofer
    75W, 5.2" Bass Reflex
  • Surround (L/R)
    45WX2
    Playable Formats
    DVD / VCD / Super VCD / CD, MPEG 1/2 L2, WMA

AMPLIFIER

  • CH
    5.1
    POWER OUTPUT
    300W
  • Front L/R
    45W x 2(3Ω)
    Center
    45W (3Ω)
  • Surround L/R
    45W x 2(3Ω)
    Sub-Woofer
    75W(6Ω)

CONVENIENCE

  • Speaker Level Trim
    Yes
    Speaker Distance (channel delay)
    Yes
  • Test Tone
    Yes
    Mute
    Yes
  • Dimmer
    Yes
    Sleep
    Yes
  • Volume on TV
    Yes
    Dynamic Range Control
    Yes
  • Meta Data Showing GraceNote (CD/Streaming/File)
    No/No/No
    Thumbnail Movie/Photo
    No/No
  • Bluetooth (Rx / Tx)
    No/No

DESIGN (MAINSET)

  • Front & Rear cabinet (tray)
    Yes

3D COMPATIBILITY

  • 3D / 2D
    No/No

DISC & AV FORMAT

  • DVD(NTSC)
    Yes
    DVD(PAL)
    Yes
  • DVD-R
    Yes
    DVD-RW(Video/VR Mode)
    Yes/No
  • DVD+R
    Yes
    DVD+RW(Video mode)
    Yes
  • Audio CD
    Yes
    CD-R/CD-RW
    Yes
  • Video CD/Super VCD
    Yes/Yes
    MPEG2
    Yes
  • LPCM
    Yes
    Dolby Digital
    Yes
  • MPEG 1/2 L2
    Yes
    MP3/ID3 Tag
    Yes/Yes
  • Graphics/Subtitle Foramt
    2bit/ 8bit Sub-picture
    Video DAC
    108MHZ/12bit
  • NTSC/PAL Hz
    60Hz / 50Hz
    VBI
    Yes
  • NTSC⇔PAL Conversion
    Yes
    Last Scene memory
    Yes

IN/OUT

  • Composite Video Output
    Yes
    Front Display
    FLD
  • USB
    1
    Audio Input Audio L/R
    Yes
  • Radio Antenna FM/AM
    Yes/No
    Speaker Terminal Composing of channel
    5.1
  • Speaker Terminal Terminal Type
    Push in (Spring)

LG SMART FUNTIONS

  • Full Browser Flash 10 / HTML 5 support
    No/No/ No

POWER

  • Power Consumption (in Operation)
    TBD
    SMPS
    Wide
  • Power Off Consumption (in Standby)
    0.5W↓

PLAYBACK CAPABILITY

  • Fast Forward / Reverse
    Yes/Yes
    Pause
    Yes
  • Random Play Mode
    Yes
    Repeat Play - A-B
    Yes
  • Repeat Play - Chapter
    Yes
    Repeat Play - Title/Track
    Yes
  • Resume Stop
    Yes
    Search - Chapter
    Yes
  • Search - Time
    Yes
    Search - Title/Track
    Yes
  • Slow Forword / Reverse
    Yes/Yes
    Step Forward / Reverse
    Yes/No

PHYSICAL

  • Size (W x H x D) mm Main
    365 X 65 X 270
    Front Speaker
    113 X 113 X84
  • Center Speaker
    114 X 113 X84
    Rear Speaker
    115 X 113 X84
  • Subwoofer
    156x 325 x 260

RADIO

  • Tuner Type
    PLL
    Tuning Up/Down
    Yes
  • Preset Up/Down
    Yes
    Band FM / FM(RDS) / AM
    Yes/ No / No
  • Preset Memory
    50 Station

SPEAKER

  • Front/Rear/Center Model Name
    S34S1-S
    Front/Rear/Center SPL
    82dB
  • Front/Rear/Center System
    Colsed Type
    Front/Rear/Center Woofer Unit
    2.5" Paper Cone (1EA)
  • Front/Rear/Center Impedance
    Front/Rear/Center Magnetic Shielding
    Non-Shield
  • Subwoofer Model Name
    S34S1-W
    Subwoofer SPL
    84dB
  • Subwoofer System
    Bass Reflex
    Subwoofer Woofer Unit
    5.25 " Cone
  • Subwoofer Impedance
    Subwoofer Magnetic Shielding
    Non-Shield

FEATURE LIST & ACCESSORY KIT

  • Remote Control Unit Type
    LA1
    Remote Control Unit Unified
    Yes
  • Remote Control Unit Battery(Size)
    AAA*1
    Batteries (Remote Controller)
    Yes
  • FM / AM Antenna
    Yes/No
    Warranty Card
    Yes
  • RCA Code(Video), Yellow, 1P
    Yes
    Carton Box Type
    Flexso
