S126NH
Cooling & Heating
  • Jet Cool
  • Tropical Compressor
  • Gold Fin
  • Auto Cleaning

component-OBScountrySelectDesc

Cooling & Heating

AIR CIRCULATION

  • Indoor, Max
    8
    Outdoor, Max
    35

COMPRESSOR

  • Compressor
    Rotary

CIRCUIT BREAKER

  • Circuit Breaker(A)
    15

CONNECTING CABLE

  • AWG#:P*㎟
    3*1.5+2*0.75

CONNECTING TUBE (Ø. SOCKET FLARE)

  • Gas Side, mm(in)
    12.7(1/2)
    Liquid Side, mm(in)
    6.35(1/4)
  • Length,std, m(in)
    5

COOLING CAPACITY

  • Btu/hr
    12,000
    kcal/h
    3,024
  • W
    3,517

DIMENSION

  • Indoor (W*H*D)(mm)
    840*270*153
    Outdoor (W*H*D)(mm)
    770*245*540

E.E.R.

  • Btu / h.W
    9
    kcal / hW
    2.24
  • W / W
    2.60

FUNCTIONS

  • CHAOS Wind (Auto Wind)
    Yes
    Hot Start
    Yes
  • Jet Cool
    Yes
    Remote Controller Type
    Wireless LCD
  • Restart Delay (minute)
    3
    Steps, Fan/Cool
    3/4
  • Temperature Control
    Thermistor
    Timer
    7Hr,On/Off

HEATING CAPACITY

  • Btu/h.
    12,000
    kcal/h
    3,024
  • W
    3,517

NET WEIGHT

  • Indoor (kg(lbs))
    8
    Outdoor (kg(lbs))
    35

NOISE LEVEL (SOUND PRESSURE, 1M)

  • utdoor,Max. dB(A)±3
    40
    Indoor,High. dB(A)±3
    51

OUTDOOR H/E

  • Outdoor H/E
    GOLD FIN

POWER INPUT

  • Cooling(W)
    1,350
    Heating(W)
    1,250

POWER SUPPLY

  • Ø / V / Hz
    1,220,50

POWER CORD

  • AWG#:P*㎟
    3*1.5

RUNNING CURRENT

  • Cooling(A)
    6.40
    Heating(A)
    5.90

REFRIGERANT(R-22)CHARGE

  • g(oz)
    680
