S1868C
cooling only
  • 10m windblast
  • Jet Cool
  • Optimized Airflow
  • Tropical Compressor

component-OBScountrySelectDesc

cooling only

DIMENSION

  • Indoor (W*H*D)(mm)
    1,030*325*250
    Indoor (W*H*D)(inch)
    40.6*12.8*9.8
  • Outdoor (W*H*D)(mm)
    31.9*22.3*10.6
    Outdoor (W*H*D)(inch)
    810*568*270

FILTER

  • 3M Multi Protection Filter
    Yes
    Prefilter(washable/anti-fungus)
    Yes
  • Plasma Filter
    Yes

HIGHLIGHTS

  • Cooling (Min / Rated / Max) T1
    5.04 KW, 17353 Btu/h
    Heating (Min / Rated / Max) T3
    4.45 KW , 15194 Btu/h.
  • Power Input (Cooling) T1-W
    1980
    Power Input (Cooling) T3-W
    2325
  • Power Supply
    1 / 220-240 / 50 - Ø / V / Hz
    Running Current (Cooling) T1-A
    8.7
  • Running Current (Cooling) T3-A
    10.4
    Starting Current (Cooling) T1-A
    8.7
  • Starting Current (Cooling) T3-A
    10.4

NET WEIGHT

  • Indoor (kg(lbs))
    14 (30.9)
    Outdoor (kg(lbs))
    39 (86.0)

OPERATION RANGE

  • Cooling (outdoor) °C(°F)
    21~54(69.8~129.2)

OTHER FUNCTIONS

  • Additional Refrigerant charge
    20 g/m
    Circuit Breaker
    20 A
  • Max. Elevation Difference
    15 (49.2) m(ft)
    Max. Piping Length
    20 (65.6) m(ft)
  • Moisture Removal
    2.0 l/h
    Refrigerant & Charge
    R22,850 (30) g(oz)

PERFORMANCE

  • Air Flow Rate (Indoor, Max)
    12.6 (445) m3/min(CFM)
    Air Flow Rate (Outdoor, Max)
    32.0 (1,130) m3/min(CFM)
  • EER
    2.6 T1-W/W , 8.7 T1-Btu/h.W , 1.9 T3-W/W , 6.5 T3-Btu/h.W
    Noise Level © (Indoor,H / M / L / LL)
    40 / 37 / 34 / dB(A)±3
  • Noise Level © (Outdoor, Max)
    54 dB(A)±3

PIPING CONNECTIONS

  • Liquid Side (mm(in))
    6.35 (1/4)
    Gas Side (mm(in))
    12.70 (1/2)
