Discontinued
S246SC
Titan Jetcool
  • Cools even at 58°C
  • Corrosion Resistance
  • Faster Cooling
  • Multi Directional Cooling
  • Dual Protection Filter

component-OBScountrySelectDesc

Titan Jetcool

COOLING (MIN/RATED/MAX)

  • T1 kW
    6.7
    T1 Btu/h.
    23,000
  • T3 kW
    5.8
    T3 Btu/h.
    19,700

POWER INPUT (COOLING)

  • T1(W)
    2,640
    T3(W)
    3,010

RUNNING CURRENT (COOLING)

  • T1(A)
    11.9
    T3(A)
    13.6

EER

  • T1(W/W)
    2.6
    T1(Btu/h.W)
    8.7
  • T3(W/W)
    1.9
    T3(Btu/h.W)
    6.52

POWER SUPPLY

  • Ø,V,Hz
    1 / 220-240 / 50

GENERAL SPECIFICATIONS

  • Compressor
    Rotary
    Air Flow Rate (Indoor,Max) m³/min(CFM)
    14.6(516)
  • Air Flow Rate (Outdoor,Max) m³/min(CFM)
    41.7(1,473)
    Noise Level © (Indoor,H/M/L/LL) dB(A)±3
    45 / 40 / 36 / -
  • Noise Level © (Outdoor,Max) dB(A)±3
    56
    Refrigerant & Charge g(oz)
    R22, 1,030(36.3)
  • Additional Refrigerant charge g/m
    30
    Circuit Breaker A
    30

NET WEIGHT

  • Indoor (kg(lbs))
    13(28.7)
    Outdoor (kg(lbs))
    46(101.4)

OPERATION RANGE (MIN~GUARANTEED~MAX)

  • Cooling(Outdoor) °C
    21~54~58

MAX. PIPING LENGTH

  • m(ft)
    20(65.6)

MAX. ELEVATION DIFFERENCE

  • m(ft)
    15(49.2)

PIPING CONNECTIONS

  • Liquid Side (mm(in))
    9.52(3/8)
    Gas Side (mm(in))
    15.88(5/8)

DIMENSIONS

  • Indoor(W*H*D)(mm)
    1,090*300*180
    Indoor(W*H*D)(inch)
    42.9*11.8*7.1
  • Outdoor(W*H*D)(mm)
    870*655*320
    Outdoor(W*H*D)(inch)
    34.3*25.8*12.6

FILTER

  • Dual Protection Filter(Washable/Anti-fungus)
    Yes
