All Spec
GENERAL SPECIFICATION
-
Cooling Capacity
6440W
-
Heating Capacity
6880W
-
EER
2.69 W/W
-
Power Supply
1/220/50 (Φ / V / Hz)
-
Power Factor
94.5%
-
Moisture Removal
2.8ℓ/h.
-
Circuit Breaker
30A
-
Power Cord
3x2.5 P*㎟
-
Connecting Cable
3x2.5+2x0.75 P*㎟
POWER INPUT (W)
-
Cooling
2390
-
Heating
2400
RUNNING CURRENT (A)
-
Cooling
11.5
-
Heating
11.6
AIR CIRCULATION ㎥/MIN(CFM)
-
Indoor,Max
15.0 (530)
-
Outdoor,Max
48 (1695)
AIR FLOW
-
Air supply outlet
1
-
Airflow direction control(left & right)
Manual
-
Airflow direction control(up & down)
Auto
-
Auto swing(left & right)
Manual
-
Auto swing(up & down)
Auto
-
Airflow steps(fan/cool/heat)
-/4/3
-
Chaos swing
Yes
-
Jet cool(Power wind)
Yes
AIR PURIFYING
-
Prefilter(washable / anti-fungus)
Yes
NOISE LEVEL (SOUNDPRESSURE,1M)
-
Indoor,High dB(A)±3
45
-
Med. dB(A)±3
40
-
Low dB(A)±3
35
-
Outdoor,Max dB(A)±3
55
RELIABILITY
-
Hot start
Yes
-
Self diagnosis
Yes
-
Soft dry operation
Yes
INDIVIDUAL CONTROL
-
Wireless remote controller(simple)
Yes
CONVENIENCE
-
Auto restart operation
Yes
-
Forced operation
Yes
-
Setting Temperature Range (Cooling)
18-30
-
Setting Temperature Range (Heating)
16-30
-
Temperature Increment
1
-
Timer(Hr)
Yes (7h On/Off)
COMPRESSOR
-
Type
ROTARY
-
Model
QP442PEB
-
Maker
LG
-
Capacity kcal/h.(Btu/h.)
6678/6728(26500/26700)
-
Motor Type
PSC
-
Motor Input W
2545/2609
-
Oil Type
NM56 or 4GSI
-
Oil Charge cc
1130
-
O.L.P Name
Internal Type
BLOWER MOTOR
-
Type
Cross Flow Fan
-
Output W
25.6
FAN MOTOR
-
Type
Axial fan
-
Motor Type
AC Induction
-
Motor Output
72W
CONNECTING TUBE (Φ. SOCKET FLARE)
-
Liquid Side mm(in)
9.52(3/8")
-
Gas Side mm(in)
15,8(5/8")
-
Length,std m(in)
5(196)
DIMENSION (W*H*D)
-
Indoor
1090*300*180 mm
-
Outdoor
870*800*320mm
NET WEIGHT KG(LBS)
-
Indoor
12(26,46)
-
Outdoor
65(143.3)
