Cooling Capacity (Min ~ Rated ~ Max)
1.08 ~ 5.31 ~ 5.36 KW
3,685 ~ 18,114 ~ 18,300 Btu/h
Heating Capacity (Min ~ Rated ~ Max)
1.08 ~ 5.71 ~ 6.10 KW
3,685 ~ 19,480 ~ 20,800 Btu/h
Power Input - Cooling (Min ~ Rated ~ Max)
238 ~ 1,630 ~ 1,900 W
Power Input - Heating (Min ~ Rated ~ Max)
238 ~ 1,650 ~ 1,800 W
Running Current - Cooling (Min ~ Rated ~ Max)
1.10 ~ 7.50 ~ 9.10 A
Running Current - Heating (Min ~ Rated ~ Max)
1.10 ~ 7.40 ~ 9.10 A
EER
3.26 W/W
11.11 (Btu/h)/W
SEER
14.97
COP
3.46 W/W
11.81 (Btu/h)/W
Power Supply
1, 220, 50 (Φ/V/Hz)
Available Voltage Range
187 ~ 276 V
Power Factor - Cooling/Heating
95%/95%
Indoor - Air Flow Rate (Cooling, Max/H/M/L)
19.3/13.5/12/9 m³/min
670.9/476.8/423.8/317.8 CFM
Indoor - Air Flow Rate (Heating, Max/H/M/L)
20/14/13/9.5 m³/min
706.2/494.4/459/335.5 CFM
Indoor - Sound Pressure Level (Cooling, H/M/L/SL)
44/39/34/31 dB (A)
Indoor - Sound Pressure Level (Heating, H/M/L)
44/39/34 dB (A)
Indoor - Dimensions (W × H × D) - Net
998 × 345 × 210 mm
39-9/32 × 13-19/32 × 8-9/32 in.
Indoor - Dimensions (W × H × D) - Shipping
1080 × 422 × 281 mm
42-17/32 × 16-5/8 × 11-1/16 in.
Indoor - Weight (Net)
26.2 (11.9) lb. (kg)
Indoor - Weight (Shipping)
30.9 (14) lb. (kg)
Indoor - Disconnect Switch
20A
Indoor - Exterior Color Code
Munsell 7.5BG 10/2 (RAL 9016)
Outdoor - Air Flow Rate (Max)
38.0m³/min
1342CFM
Outdoor - Fan Motor Speed (Cooling, Min ~ Max)
200 ~ 900 rpm
Outdoor - Fan Motor Speed (Heating, Min ~ Max)
200 ~ 900 rpm
Outdoor - Sound Pressure Level (Cooling, Rated)
54dB (A)
Outdoor - Sound Pressure Level (Heating, Rated)
56dB (A)
Outdoor - Dimensions (W × H × D) - Net
770 × 545 × 288 mm
30 - 5/16 × 21 - 15/32 × 11 - 11/32 in.
Outdoor - Dimensions (W × H × D) - Shipping
925 × 593 × 393 mm
36 - 13/32 × 23 - 11/32 × 15 - 15/32 in.
Outdoor - Weight (Net)
75 (34) lb. (kg)
Outdoor - Weight (Shipping)
87.1 (39.5) lb. (kg)
Outdoor - Max. Fuse Size
20A
Outdoor - Exterior Color Code
Munsell 9.54Y 8.34/1.31 (RAL 9001)
Outdoor - Operation Range (Cooling)
64.4 ~ 118.4 (18 ~ 48) °F (°C) DB
Outdoor - Operation Range (Heating)
23 ~ 64.4 (-5 ~ 18) °F (°C) WB
Recommened Fuse Amps
20A
Power Supply Cable
3 × 14 (1.5) No. × AWG (mm²)
Power Supply to Unit
Outdoor
Power and Communication Cable
4 × 18 (0.75) No. × AWG (mm²)
Piping - Size (Liquid)
ø1/4 (ø6.35) in. (mm)
Piping - Size (Gas)
ø1/2 (ø12.7) in. (mm)
Piping - Connections Method (Indoor/Outdoor)
Flared
Drain Hose Size (O.D, I.D)
27/32, 5/8 (21.5, 16.0) in. (mm)
Between Indoor & Outdoor - Piping Length (Min/Standard/Max)
11.8/24.6/65.6
(3.6/7.5/20) ft. (m)
Between Indoor & Outdoor - Piping Length (No Charge)
24.6 (7.5) ft. (m)
Between Indoor & Outdoor - Max. Elevation Difference
32.8 (10) ft. (m)
Between Indoor & Outdoor - Piping Connection Heat Insulation
Both liquid and gas pipes
Refrigerant - Type
R410A
Refrigerant - Pre Charge
43.4 (1230) oz. (g)
Refrigerant - Additional charge
0.22 (20) oz./ft. (g/m)
Refrigerant - Control
Capillary
Refrigerant - Global Warning Potential
2087.5
Refrigerant - t-CO₂ eq
2.568
Defrost Method
Reverse Cycle
Tool Code (Chassis) (Indoor/Outdoor)
SK/UL2
Compressor - Type
Twin Rotary
Compressor - Model
GAT156MAD
Compressor - Motor Type
BLDC
Compressor - Oil Type/Maker
POE (RB68A)/Sun Oil or Jx Nippon
Compressor - Oil Charge
400cc
Compressor - Manufacturer/Country of Origin
LG Electronics/China
Fan (Indoor) - Type
Cross Flow Fan
Fan (Indoor) - Motor Output
30V
Fan (Outdoor) - Type
Propeller Fan
Fan (Outdoor) - Motor Type
BLDC
Fan (Outdoor) - Motor Output
43V
Fan (Outdoor) - Motor Insulation
Class E
Fan (Outdoor) - Motor Enclosure/Ingress Protection
TEAO/IPX4
Heat Exchanger - Evaporator (Material, Tube/Fin)
Cu/Al
Heat Exchanger - Evaporator ((ø x Row x Column x FPI x L) x Qty.)
(ø7 x 2 x 16 x 20 x 744) x 1
Heat Exchanger - Evaporator (Corrosion Protection)
PCM
Heat Exchanger - Evaporator (Fin Type)
Slit
Heat Exchanger - Condenser (Material, Tube/Fin)
Cu/Al
Heat Exchanger - Condenser ((ø x Row x Column x FPI x L) x Qty.)
(ø7 x 2 x 24 x 18 x 823) x 1
Heat Exchanger - Condenser (Corrosion Protection)
Gold
Heat Exchanger - Condenser (Fin Type)
Louver
