All Spec
GENERAL SPECIFICATIONS
-
Capacity - Cooling (Rated)
-
13.51kW
46,100Btu/h
-
Capacity - Heating (Rated)
-
14.65kW
50,000Btu/h
-
Power Input - Cooling (Rated)
-
4.65kW
-
Power Input - Heating (Rated)
-
4.15kW
-
Running Current - Cooling (Rated)
-
20.3 A
-
Running Current - Heating (Rated)
-
18.2 A
-
Power Supply (V , Ø , Hz)
-
230, 1, 60
-
Wiring Connections - Power Supply Cable (included Earth)
-
3C No. x 6.0 mm2 (10AWG)
-
Dimensions - (WxHxD)
-
950 x 1,360 x 330 mm
37-13/32 x 54-11/32 x 13 inch
-
Net Weight
-
93.5kg (206.1lbs)
-
Compressor - Type
-
Twin Rotary
-
Compressor - Model
-
GPT442MAB Model x 1 No.
-
Compressor - Motor type
-
BLDG
-
Compressor - Motor Output
-
4,000W (at 60Hz) x 1 No.
-
Refrigerant - Type
-
R410A
-
Refrigerant - Precharged Amount
-
3,400g (119.9oz)
-
Refrigerant - Chargeless - Pipe Length
-
5m (16.4ft)
-
Refrigerant - Additional Charging Volume
-
40g/m (0.43oz/ft)
-
Refrigerant - Control
-
Electronic Expansion Valve
-
Refrigerant Oil - Type
-
FVC68D (PVE)
-
Refrigerant Oil - Charged volume
-
1,300cc x 1 No.
-
Heat Exchanger - (Row x Column x FPI) x No.
-
(2 x 32 x 16) x 2
-
Fan - Type
-
Propeller
-
Fan - Air Flow Rate
-
120 x 2m3/min
-
Fan Motor - Type
-
BLDC
-
Fan Motor - Output
-
124.2W x 2 No.
-
SoundPressure Level - Cooling (Rated)
-
62dB (A)
-
SoundPressure Level - Heating (Rated)
-
62dB (A)
-
Piping Connections - Liquid (Outer Dia.)
-
Ø9.52mm (3/8inch)
-
Piping Connections - Gas (Outer Dia.)
-
Ø19.05mm (3/4inch)
-
Piping Length (Max.)
-
30m (98.4ft)
-
Maximum Height defference - Outdoor Unit ~ Indoor Unit (Max.)
-
20m (65.6ft)
-
Opefatio Range (Outdoor Teriperatvre) - Cooling (Min. ~ Max.)
-
0°C (32.0°F) ~ 54DB (129.2DB)
-
Opefatio Range (Outdoor Teriperatvre) - Heating (Min. ~ Max.)
-
-5°C (23.0°F) ~ 18WB (64.4WB)
