LWS3063BD

4.7 cu. ft. Single Built-In Wall Oven

Black Stainless Steel
$1,999.99
4.7 cu. ft. Single Built-In Wall Oven
$ 1,999.99

DIMENSIONS/CLEARANCES/WEIGHT

    • Shipping Weight (lbs)
    • Approx. 81.2 kg (179lbs)
    • Weight (Product)
    • Approx. 71.2 kg (157lbs)
    • Depth
    • 24 3/8"
    • Height
    • 29 15/16"
    • Width
    • 29 3/4"
    • Carton Dimensions (in) (W x H x D)
    • 33"(W) x 30"(D) x 34"(H)
    • Exterior (WxHxD)
    • 29-3/4"(W) x 29-5/16"(H) x 24-3/8"(D)
    • Cutout
    • 28-1/2"(W) x 29"(H) x 23-1/2"(D)

OVEN FEATURES

    • Bake Element
    • 2,500 watts
    • Bake element type
    • Hidden (8 pass)
    • Broil Element
    • 2,500 watts inner / 1,500 watts outer
    • Variable broil
    • Yes( Full,Center / High,Med,Low)
    • Broil element pass
    • 8
    • Cleaning
    • EasyClean®/Self Clean (3,4,5 hours)
    • Variable cleaning time
    • Yes (3,4,5 hrs)
    • Capacity (cu.ft)
    • 4.7
    • Interior Color
    • Blue
    • 12 hrs. shut-off
    • Yes
    • - # of light
    • 2 (Halogen Lamp - 2 dimension lighting)
    • Proof
    • Yes
    • Variable warm
    • Yes (High,Med,Low)
    • Favorites menu
    • 3 (1. Bread,2. Meat,3. Chicken)
    • Color & Material
    • STS Finish(Al) / Black Stainless
    • # of rack position
    • 5
    • Convection Conversion
    • Yes
    • Convection element
    • Yes (2,000 watts Sheath heater)

SUMMARY

    • EasyClean®
    • Yes
    • Single Oven
    • Yes
    • Self + EasyClean®
    • Yes
    • ADA Compliant
    • Yes

WARRANTY/UPC

    • UPC
    • 048232335491
    • Parts & Labor
    • 1 Year

ACCESSORIES

    • Grid
    • 1
    • Heavy Duty Rack
    • 2
    • Spray Water Tank
    • 1
    • Broiler pan
    • 1

POWER/RATINGS

    • Rating
    • 4.1 KW
    • Electrical Supply
    • 120/240 VAC,120/208 VAC
    • Max. Amp Load
    • 17.3 A

What people are saying

Rated 4 out of 5 by from Looks great... however needs a base plate cover Just had the oven and love the look/color. Can’t wait to start using it. However the bottom part oven does not present a finished look. We will have to caulk/fill up to the bottom base plate which will not look ‘finished’, in our opinion.
Date published: 2020-07-09
Rated 5 out of 5 by from Wall Oven is Great! We replaced our slip in oven and installed this new LG LWS3063ST wall oven and it works perfectly, still getting used to the quicker cooking due to the convection feature. The look is very clean and contemporary.
Date published: 2020-03-06
Rated 5 out of 5 by from Works well So happy with our purchase. Great looking and the oven performs very well. We love it.
Date published: 2020-03-01
  • y_2020, m_10, d_28, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_39
  • loc_en_US, sid_MD05601256, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 3ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Want to replace current wall oven w/cook top over, w/LWS3063BD single wall oven, and MUST have EXTERIOR oven BOX dimension to ensure cook top will fit above. Not listed in manual dimensions, called customer service 3x. No display models in my area.

Asked by: KLF16
You can visit the product information page for the LG 4.7 cu. ft. Single Built-In Wall Oven, Model # LWS3063D on our site and click on the Support tab to find a PDF copy of the Installation Guide that you can download and review where the required junction box should be placed and review an illustrated diagram with measurements for where gas or electric cooktops can be installed above the wall oven...^IFV
Answered by: Ivanf
Date published: 2020-01-31

Is the Oven designed to mount under the counter with a stove top above it

Asked by: Cimmark
The cooktop and oven can be installed together, as long as proper clearances are observed.
Answered by: ChrisPSM
Date published: 2020-01-03

Not sure how this can be ADA compliant because no matter how low I install it, in a wheel chair I burn myself or have to get danger close to be able to use it. I need an oven with retractable door or cafe style doors.

Asked by: Charlie pf tje 11
If you're in need of some guidance with using your range, please head to our support page at @LGUSSupport on Twitter or shoot us a private message on Facebook at https://www.facebook.com/LGUSA/ so a specialist can help out. ^CP
Answered by: ChrisPSM
Date published: 2019-12-09

Not sure how this can be ADA compliant because no matter how low I install it, in a wheel chair I burn myself or have to get danger close to be able to use it. I need an oven with retractable door or cafe style doors.

Asked by: Charlie pf tje 11
If you're in need of some guidance with using your range, please head to our support page at @LGUSSupport on Twitter or shoot us a private message on Facebook at https://www.facebook.com/LGUSA/ so a specialist can help out. ^CP
Answered by: ChrisPSM
Date published: 2019-12-09

CAN YOU USE THE GLIDING RACK FOR THIS UNIT

Asked by: MCHILDERS
Regrettably, there aren't any Gliding Racks that are compatible with the LG 4.7 cu. ft. Single Built-In Wall Oven, Model # LWS3063BD...^IFV
Answered by: Ivanf
Date published: 2019-11-20

What size halogen bulbs go inside oven? 2 of 3 are out.

Asked by: SueZeQ
The oven light is a standard 10-watt halogen bulb for ovens. If you have additional questions, you can contact our Customer Support by any of the below options: Phone: 1-800-243-0000 LiveChat: https://www.lg.com/us/support/chatbot Email: https://www.lg.com/us/support/email-appointment Facebook Messenger: https://www.facebook.com/LGUSA/ Twitter: @LGUSSupport The LG Community Forum is also a great resource for getting help from other LG customers: https://lgcommunity.us.com/
Answered by: ChrisPSM
Date published: 2019-09-30

if is safe to put the cooktop LCE3010 above the wall oven LW s3063??

Asked by: mamagolfer
The installation instructions for the LG 4.7 cu. ft. Single Built-In Wall Oven, Model # LWS3063BD state that Gas or Electric cooktops may be installed over the oven and the installation instructions for the LG 30" Electric Cooktop, Model # LCE3010SB strongly advise to keep a distance of 2 3/4" between the cooktop and the oven...^IFV
Answered by: Ivanf
Date published: 2020-10-07

Is there a trim kit available for the LWS3063ST?

Asked by: CoCo13
The LG 4.7 cu. ft. Single Built-In Wall Oven, Model # LWS3063ST has a trim around it that overlaps the cutout that it is designed to fit into...^IFV
Answered by: LGJoel
Date published: 2020-05-10
