KEY FEATURES

  • 27 cu. ft. Smart InstaView® Counter-Depth MAX™ French Door Refrigerator
  • 6.3 cu ft. Smart Wi-Fi Enabled True Convection InstaView® Electric Range with Air Fry
  • 1.7 cu. ft. Over-the-Range Microwave Oven
  • Top-Control Dishwasher with 1-Hour Wash & Dry, QuadWash® Pro, and Dynamic Heat Dry™
  • ThinQ Offer: Get an extra 1-year limited warranty (up to $185 value) through 4/02/25. Terms applyᶲ
  • LG 65 Inch Class UHD Series 4K UHD TV with webOS 24
Enhanced Kitchen Package with Electric Range
$ 4,099.00
Download Energy Guide

Capacity

    • Freezer (cu.ft.)
    • 8.6 cu.ft.
    • Refrigerator (cu.ft.)
    • 17.9 cu.ft.
    • Total Capacity (cu.ft.)
    • 26.5 cu.ft.

Convenience

    • ADA Compliant
    • Yes
    • Auto Closing Door Hinge
    • Yes
    • Child Lock
    • Yes
    • Door Alarm
    • Yes
    • LoDecibel™ Quiet Operation
    • Yes
    • Proactive Customer Care
    • Yes
    • Sabbath Mode
    • Yes
    • Temperature Controls
    • Electronic/Digital
    • Wifi Eclipse Display
    • Electronic/Digital

Cooling

    • Compressor Type
    • Smart Inverter Compressor
    • Evaporator
    • 1
    • Fresh Air Filter
    • Yes
    • Temperature Sensors
    • 2
    • Type
    • No

Dimensions/Clearances/Weights

    • Carton Dimensions (WxHxD)
    • 38" x 72" x 31"
    • Case Edge Clearance (Door Fully Open)
    • 21"
    • Counter Depth
    • Yes
    • Depth (to Hinge Cover)
    • 18.25"
    • Depth with Handles
    • 31.63"
    • Depth without Door
    • 24.75"
    • Depth without Handles
    • 29.12"
    • Door Edge Clearance with Handle
    • 4.25"
    • Door Edge Clearance without Handle
    • 2.25"
    • Height (Floor to Top of Drawer)
    • 70.25"
    • Height to Top of Case
    • 68.88"
    • Height to Top of Door Hinge
    • 70.25"
    • Installation Clearance
    • Sides 1/8", Top 1", Back 2"
    • Standard Depth
    • No
    • Weight (Unit/Carton)
    • 291 lbs. / 313 lbs.
    • Width
    • 35.75"
    • Width (Door Open 90˚ with Handle)
    • 44.88"
    • Width (Door Open 90˚ without Handle)
    • 40"

Energy

    • Energy Consumption (kWh/Year)
    • 632
    • ENERGY STAR® Qualified
    • Yes

Freezer

    • Door Type
    • Pull Drawer
    • Drawer Divider
    • No
    • Drawers/Shelves
    • 2-Tier Organization
    • DuraBase™ Solid Drawer Base
    • Yes
    • Freezer Handle
    • SmartPull™ Handle
    • Freezer Light
    • LED Lighting

Limited Warranty & UPC

    • Compressor (Parts & Labor)
    • 5 Years
    • Linear Compressor (Parts Only)
    • 6-10 Years
    • Parts & Labor
    • 1 Year
    • Sealed System (Parts & Labor)
    • 5 Years
    • UPC
    • 195174039250

Refrigerator

    • Cantilevered Shelves
    • Yes
    • Cool Guard
    • Yes
    • Crisper Bins
    • 2 Crispers
    • Door Bin Construction
    • 1 Piece (Clear)
    • Folding Shelf
    • no
    • Glide N’ Serve™ Drawer
    • Yes
    • Handle Type
    • Bar
    • No. of Door Bins
    • 8 Total (2 Adjustable Gallon Sized)
    • No. of Shelves
    • 4 Split (4 Fixed)
    • Shelf Construction
    • Spill Protector™ Tempered Glass

Summary

    • Display Type
    • Smooth Touch Control / White LED

Refrigerator ThinQ® Smart Features

    • ThinQ® Smart Technology
    • Yes
    • ThinQ Care™
    • Yes
    • ThinQ UP™
    • Yes

Water & Ice System

    • Daily Ice Production (lbs)
    • 2.5 lbs. (F/Cubed)
    • Dispenser Type
    • Internal Water Dispenser
    • Ice Storage Capacity (lbs)
    • 4.0 lbs
    • Ice System
    • IcePlus™
    • Water Filter
    • LT1000P

Appearance

    • Handle Type
    • Curved Bar
    • All Available Colors
    • PrintProof® Stainless Steel
    • Cooktop Finish
    • Ceramic Glass, Stainless Steel
    • Knobs
    • Stainless Steel Appearance, Weighted
    • Oven Door Feature
    • InstaView® & WideView™ Window

Capacity

    • Total Capacity
    • 6.3 cu.ft.

Cooktop

    • Element Size/Wattage - Center
    • 7" - 100W
    • Element Size/Wattage - Left Front
    • 3200W (9") / 1400W (6") (UltraHeat™)
    • Element Size/Wattage - Left Rear
    • 6" / 1200W
    • Element Size/Wattage - Right Front
    • 12" 9" 6" - 3,000W / 2,200W / 1,100W
    • Element Size/Wattage - Right Rear
    • 6" / 1200W
    • Hot Surface LED Indicator
    • Yes
    • Type
    • Radiant, Ceramic Glass

Controls

    • Kitchen Timer
    • Yes
    • Oven Control Lock
    • Yes
    • Oven Control Type
    • SmoothTouch™ Glass Controls
    • Sabbath Mode
    • Yes
    • Timed Cook
    • Yes

Dimensions/Clearances/Weight

    • Cabinet Width (in)
    • 30"
    • Overall Depth (in) - including handle
    • 28.87"
    • Overall Height (in)
    • 46.5"
    • Overall Width (in)
    • 29.87"
    • Shipping Dimensions (WxHxD)
    • 32 1/2" x 51" x 30 1/2"
    • Shipping Weight (lbs)
    • 191 lbs
    • Product Weight (lbs)
    • 168 lbs

Drawer Features

    • Type
    • Storage

Features

    • EasyClean® Interior
    • Yes

Lower Oven Features

    • # of lights
    • 7

Oven Features

    • Bake Element
    • 3400W
    • Broil Element
    • 4200W
    • Broil element pass
    • 3
    • Convection Conversion Auto-Adjust
    • Yes
    • Door Lock
    • Yes
    • Freestanding
    • Yes
    • Hidden Bake Element
    • Yes
    • Oven Cleaning Type
    • EasyClean® + Self Clean
    • Oven Cooking System
    • True Convection
    • Oven Light
    • Halogen
    • Oven Modes
    • Bake, Broil, Air Fry, Proof, EasyClean®, Self Clean, Convection Bake, Convection Roast Keep Warm, Frozen Meal, Slow Cook, Favorite
    • Oven Type
    • Single Oven
    • Self-Clean Oven Door Lock
    • Automatic

Power/Ratings

    • Amp Rating at 208V
    • 46.6
    • Amp Rating at 240V
    • 53.8
    • KW Rating at 208V
    • 9.7
    • KW Rating at 240V
    • 12.9
    • Required Power Supply (amp)
    • 40a

Summary

    • Fuel Type
    • Electric
    • Series
    • LG

Cooking Appliance ThinQ® Smart Features

    • SmartDiagnosis™
    • Yes
    • ThinQ® Smart Technology
    • Yes
    • ThinQ Care™
    • Yes
    • Wi-Fi Connectivity
    • Yes
    • 3rd Party Connected Compatibility
    • Amazon Alexa, Google Assistant

Venting System

    • Vent Air Flow (CFM)
    • 5

Warranty/UPC

    • UPC
    • 048231341455
Download Energy Guide

Capacity

    • Lower Rack Dish Height Limit
    • 12.5"
    • Total Place Settings
    • 15
    • Upper Rack Dish Height Limit
    • 7.1"

Dimensions/Clearances/Weight

    • Carton Dimensions (in) (W x H x D)
    • 28 1/32" x 34 7/8" x 29 5/8"
    • Depth with Door Closed with Handle (in)
    • 26.81"
    • Depth with Door Open (in)
    • 49.25"
    • Product Dimensions (in) (W x H x D)
    • 23" 3/4 x 33 5/8" x 24 5/8"
    • Product Weight (lbs)
    • 97 lbs
    • Shipping Weight with Carton (lbs)
    • 109.13 lbs

Features

    • QuadWash® Pro
    • Yes
    • Anti-Bacterial Treatment (Drain hose)
    • Yes
    • Balanced Door
    • Yes
    • Detergent and Rinse-Aid Dispenser
    • Yes
    • Drying System
    • Dynamic Heat Dry(TM) Heated Dry
    • End of Cycle Indicator
    • Yes (Beeper + END indication on display)
    • Hidden Water Heater
    • Yes
    • LoDecibel™ Quiet Operation
    • 46 dBA
    • Number of Options
    • 7 (Flex Zone, High Temp, Dry Boost, Delay Start - Up to 12 hours, Control Lock, Night Dry, Remote Start)
    • Number of Spray Arms
    • 3 (Top, Upper, Lower)
    • Number of Wash Cycles
    • 9 (Auto, Heavy, Delicate, Normal, 1-Hour, Download CycleMachine Clean, Rinse, Express )
    • Safety Float Switch (Leaks)
    • Yes
    • SenseClean™ Wash System
    • Yes
    • Soil (Turbidity) Sensor
    • Yes
    • Tub Insulation (Damping Sheet, Sound Absorbing Material (felt), Base)
    • Yes
    • Vario Wash
    • Yes
    • 1-Hour Wash & Dry
    • Yes

Warranty & UPC

    • Control Board and Rack Parts
    • Control Board and Rack Parts 2 Years Stainless Tub and Door Liner 2 Years
    • Direct Drive Motor
    • 10 Years
    • Labor
    • 1 Year
    • Parts
    • 1 Year
    • UPC
    • 048231347709

Power Ratings

    • CEE Tier
    • 1
    • ENERGY STAR® Qualified
    • Yes
    • Energy Use (kWh/Year)
    • 238 kWh/Year

Racks and Baskets

    • BPA-Free Nylon Coated Racks and Tines
    • Yes
    • Cutlery Baskets
    • Yes
    • EasyRack™ Plus System
    • Yes
    • Fold Down Tines
    • Yes (Half on Upper & Half (Normal) on Lower)
    • Rack Handle
    • Yes

Style and Design

    • All Available Colors
    • Print Proof Black Stainless Steel, Print Proof Stainless Steel
    • Control Panel Location
    • Top Control
    • Handle
    • Curved Bar
    • Tub Material
    • NeveRust™ Stainless Steel

Dishwasher ThinQ® Smart Features

    • ThinQ Care™
    • Yes
    • SmartDiagnosis™
    • Yes
    • wi-fi Enabled
    • Yes

Appearance

    • Handle Type
    • Curved Bar
    • All Available Colors
    • PrintProof™ Stainless Steel
    • Exterior Design
    • WideView™ Window (Divided regular look)
    • Interior Color
    • Gray
    • PrintProof™ Finish
    • Yes

Capacity

    • Oven Capacity (cu. ft.)
    • 1.7 cu.ft.

Cooktop

    • Power Levels
    • 10

Controls

    • Clock
    • Yes
    • Control Location
    • Right Side
    • Control Type
    • Membrane
    • Display
    • White LED
    • Kitchen Timer
    • Yes

Dimensions/Clearances/Weight

    • Cavity (WxHxD)
    • 20 11/16" x 10 6/16" x 14 3/16"
    • Exterior (WxHxD)
    • 29 14/16" x 16 7/16" x 15 14/16"
    • Shipping Dimensions (WxHxD)
    • 33 9/16" x 20 1/16" x 19 7/16"
    • Shipping Weight (lbs)
    • 60.8 lbs
    • Product Weight (lbs)
    • 47.6 lbs

Features

    • Add 30 Seconds
    • Yes
    • Child Lock
    • Yes
    • Convection
    • No
    • Custom Settings
    • No
    • Defrost
    • Auto, Time
    • EasyClean® Interior
    • Yes
    • Turntable Diameter (in.)
    • 12.6"
    • Turntable On/Off
    • Yes

Lighting

    • Exterior Lighting
    • Halogen
    • Interior Lighting
    • LED Lighting

Oven Features

    • Air Fry
    • No
    • Proof
    • No
    • Warm Function
    • No

Power/Ratings

    • Amps / Watts
    • 14A/1600W
    • Volts
    • 120/60

Summary

    • Series
    • LG
    • Type
    • Over-the-Range Microwave

Cooking Appliance ThinQ® Smart Features

    • 3rd Party Recipe App
    • No
    • Check & Control
    • No
    • NFC Tag On
    • No
    • SmartDiagnosis™
    • Yes
    • ThinQ® Smart Technology
    • No
    • Wi-Fi Connectivity
    • No
    • ThinQ UP™
    • No

Upper Oven Features

    • Microwave Power output
    • 1000 W

Venting System

    • Exhaust Grease Filter
    • 2
    • Filtration
    • Charcoal Filter
    • Power Levels
    • 2
    • Vent Air Flow (CFM)
    • 300
    • Vent Grille Type
    • Hidden

Warranty/UPC

    • Magnetron
    • 5 Years
    • Parts & Labor
    • 1 Year
    • UPC
    • 048231346849

What people are saying

27 cu. ft. Smart InstaView® Counter-Depth MAX™ French Door Refrigerator
Rated 1 out of 5 by from LG Fridgerator Fraud Air filter NEVER installed by factory. Discovered at 6 month date when LG alert received to replace the air filter. Purchased and then tried to put new 4 inch SQUARE filter into retaining bracket, but discovered that instead of a square retaining bracket there was a trapezoid shaped plastic bracket which obviously prevented the square filter from being installed. A simple case of a defective part and a assembly line idiot who knew the issue and just ignored it. Foreign LG customer support is terrible and numerous silent periods followed by a disconnect. I guess the frustrating process is designed that way. Problem still exists with no help.
Date published: 2023-09-18
Rated 1 out of 5 by from Stopped working within 1 month. This refrigerator has been a nightmare. First, LG's delivery service kept delaying delivering my refrigerator by 3 weeks (LG did compensate me a small amount for the delay). Then after 1 month of it being installed, it stopped working. When I called to get it serviced, I was told no one could come out for 6 days. This is the only refrigerator I have in the house, so this is a huge inconvenience. LG was the only appliances I used to buy but now I will not buy another LG product ever again.
Date published: 2023-07-20
Rated 5 out of 5 by from LG Counter Depth 27 cu ft Refrigerator I have been using LG products primarily for over 3 years. All my major appliances are LG, all with no problems whatsoever. I am moving to another home and buying all new LG appliances. 1st to arrive was the 27 cu ft Refrigerator with the smart door, knock twice it lights up. Another cool feature is the internal filtered water dispenser located in the left inside sidewall, ice maker is in the freezer but it is controlled inside the right wall of the fridge. No wasted space. it works great and no space is taken in the door. The Inverter technology is so quiet, I never hear it running. I highly recommend the LG product line. I have a new top control dishwasher already installed. Tomorrow my new slide in stove arrives. Fun times at my home!!
Date published: 2023-06-27
  • y_2025, m_6, d_15, h_4
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.42
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_101
  • loc_en_US, sid_MD08002810, prod, sort_[SortEntry(order=RELEVANCE, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 49ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getContent, 25ms
  • QUESTIONS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

Compare (0)

Compare (0)
Purchase an eligible 4-piece LG Kitchen Appliance package and the 65” LG UHD Series 4K TV (65UT7570PU) in a single transaction on http://LG.com and receive instant additional savings of the TV.
Available on http://LG.com from March 13, 2025 to April 2, 2025. Savings will be reflected in the cart when all offer requirements are met. If any of the qualifying items are removed from the cart or part of the order is canceled or returned, the promotional savings will be void. Prices and offers are non-redeemable for cash and non-transferable. Availability, prices and terms of offer are subject to change without notice. This offer may not be combined with other special programs or offers.

Eligible 4-Piece LG Kitchen Appliance Packages for 65” LG UHD Series 4K TV (65UT7570PUB):



Package 1

· Refrigerator: LRFGC2706S

· Dishwasher: LDTH5554S

· Range: LREL6325F

· Microwave: MVEM1721F



Package 2

· Refrigerator: LRFGC2706S

· Dishwasher: LDTH5554S

· Range: LRGL5825F

· Microwave: MHEC1737F



Package 3

· Refrigerator: LRFLC2706S

· Dishwasher: LDTH5554S

· Range: LREL6325F

· Microwave: MVEM1721F



Package 4

· Refrigerator: LRFLC2706S

· Dishwasher: LDTH5554S

· Range: LRGL5825F

· Microwave: MVEM1721F



Package 5

· Refrigerator: LF29H8330S

· Dishwasher: LDTH5554S

· Range: LSEL6335FE

· Microwave: MVEL2137F



Package 6

· Refrigerator: LF29H8330S

· Dishwasher: DTH5554S

· Range: LSGL6335F

· Microwave: MHEC1737F

Receive an extra 1-year warranty for free when you purchase an eligible LG appliance. Simply download our ThinQ® app, connect your new appliance to Wi-Fi, and register your product to claim. Offer valid until 4/2/2025. See full terms and conditions.


Images may be simulated and dramatized for illustrative purposes. Actual features, functionality, and other product specifications may differ and are subject to change without notice. Prices, promotions, and availability may vary by model, store, and online. Prices subject to change without notice. Quantities are limited. Check with your local retailers for their final price and availability.

It’s the most popular gathering spot in the house! Make it functional, elegant, and energy-efficient with LG kitchen appliances:

Refrigerators: From French door, to side-by-side, traditional to bottom-freezer designs, LG has one of the largest and most innovative selections of refrigerators. And with LG's exclusive Linear Compressor technology, you’ll get optimum cooling, operating efficiency and reliability.

Ranges and ovens: Choose from a huge variety of gas and electric ovens and ranges, including the largest single oven in the industry. They’re more than ready for your most ambitious meals. Explore kitchen appliances designed to make cooking easy and life good.

Cooktops: Boasting features including stainless steel trim, Smooth Touch™ controls, induction bridge elements and premium-grade griddles, LG cooktops are truly style and convenience in perfect harmony.

Microwave ovens: With innovative features like Easy Clean® interiors for quick, high-performance cleaning without chemicals, plus Sensor Cook technology, you can find a stylish LG microwave oven that’s just right for your home.

Dishwashers: Dish duty just got easier. Browse LG dishwashers with intuitive controls that let you enter your desired settings with the touch of a finger.

Boasting innovative features like Linear Compressor technology for optimum cooling, operating efficiency and reliability, to Easy Clean® interiors for quick, high-performance cleaning in and out, LG kitchen appliances make quick, pleasurable work of everyday tasks like cooking, cleaning and prepping food. Create the kitchen of your dreams today. Browse all of our elegant kitchen and home appliances, including innovative refrigerators cooking appliances, microwave ovens, dishwashers and more and get the performance, style and energy efficiency you need. See how our appliances and accessories can help you create the home you’ve always wanted.
