G2 T-Mobile

  • D801

  • Discontinued Product

Key Features

  • Powerful Snapdragon™ 2.26 GHz Quad-Core Processor
  • Long-Lasting Battery - 3,000 mAh SiO+1
  • 5.2" Full HD IPS Display with Life-Like Color
  • 13 MP High Resolution Optical Image Stabilization (OIS) Camera
Type Smart Phone
Form Factor Bar
Technology GSM, UMTS, LTE*
Processor 2.26 GHz Quad-Core Processor, Qualcomm® Snapdragon™ 800 MSM8974 Chipset
Frequencies GSM 850/900/1800/1900 MHz, UTMS I/II/IV/V, LTE 2, 4, 17*
Data Transmission EDGE, GPRS, UMTS (W-CDMA), HSPA+42Mbps, LTE*
Dimensions 5.45" (H) x 2.79" (W) x 0.35" (D)
Weight 5.04 oz
Display 5.2" (1920 x 1080) Full HD IPS Display
Touch Screen Yes
Battery Capacity 3,000mAh /Embedded Li-Polymer
Talk Time 3G - 26.5 hours**
Standby Time 34 Days 17 hours**
Total Internal Memory 32 GB***
* All listed frequency support is network/carrier specific. Roaming capability and network frequency support may not be available. Check with your network provider to see if and to what extent they offer support for this device.
** Certain features may use more power and cause actual time to vary.
*** Available User Memory: 24.12 GB
LG and Android™ Enhancements
Android™ Platform Android™ 4.4.2, KitKat®
Network T-Mobile 4G LTE Network*,**
Mobile Hotspot Share a 4G data connection with other compatible wireless devices.*,**,***
Wi-Fi® Connectivity 802.11 a/b/g/n/ac
Bluetooth® Version 4.0
Direct/Android™ Beam Share via NFC (Near Field Communication)
Wireless Storage Share files with your computer via Wi-Fi®.
* T-Mobile’s 4G LTE Network not available everywhere
** All listed frequency support is network/carrier specific. Roaming capability and network frequency support may not be available. Check with your network provider to see if and to what extent they offer support for this device.
*** T-Mobile service required. Features based on carrier program availability. Additional charges may apply.
QRemote™ Control compatible TVs, Blu-ray™ players, cable provider set-top boxes, and more via infrared.
Video Player Touch Lock, Audio Effects, and Resume Play Function; supports DivX®, WMV, MP4, 3GP, and 3G2 formats
Music Player Audio Effects: supports MP3, AAC, AAC+, M4A, WAV, FLAC, and WMA formats
High Quality Sound Supporting 24-bit, 192 kHz Hi-Fi playback for FLAC and WAV files
Live Zooming Zoom in/out on videos during playback
Smart Video Video pauses automatically when phone detects eyes are not looking at the screen.
Rear-Facing Camera 13 MP Optical Image Stabilization (OIS) Full HD Rear-Facing Autofocus Camera and Camcorder with LED Flash
Front-Facing Camera 2.0 MP Full HD Front-Facing Camera
Optical Image Stabilization Clearer results by keeping imagery stable while a photo or video is taken, even in low-light conditions
Camera Resolutions Up to 4160 x 3120* (4160 x 2340 default) pixels
Multipoint Autofocus Camera detects and captures a particular subject faster and more precisely with nine autofocus points.
Shot & Clear™ Helps eliminate select moving objects in the background of a picture
Tracking Focus Zoom in on a subject while recording to track and magnify it through the scene.*
Cheese Shutter Use voice commands to capture a photo.
Shot Mode Choose from Normal, Shot & Clear*, Dynamic Tone (HDR)*, Panorama*, VR Panorama*, Burst Shot*, Beauty Shot, Dual Camera, Time Catch Shot*, Intelligent Auto*, Sports*, and Night.
Intelligent Auto Automatically identifies a scene’s characteristics and adjusts camera options such as aperture and shutter speed
Video Resolutions Up to 1920 x 1080 (60 fps; 30 fps default)
Dual Recording / Dual Camera Front and rear cameras take pictures or videos with picture-in-picture technology.
Pause & Resume Recording Pause and start in record mode for one continuous video file.
Audio Zoom Focus on a specific audio source by zooming in on the intended subject while recording video.**
Live Shot Take still shots while recording video.
Video Screenshot Capture still shots from a video during playback.
Video Editor Make and edit your own movies.
* Available only on rear-facing camera or camcorder
** Available only in landscape orientation
Slide Aside™ Three-finger swipe to the left saves up to three running apps; access tabs with a swipe to the right.
QSlide Function™ Overlay up to two QSlide app windows with adjustable sizing and transparency on primary screen.
Clip Tray™ Copy and paste multiple items to a slide-up clipboard, then select later to use or share.
Capture Plus™ Take a screen grab of an entire webpage and save to view later.
On Call Notes™ from QuickMemo™ Jot down notes during a call, and retrieve them instantly in a call log entry.
Quick Memo™ Create and share personalized memos by adding handwritten drawings or messages on-screen.
Quick Translator™ Translate sentences and phrases from 44 different languages into 66 native languages.
Knock On™ Knock twice with a fingertip to turn the display on or off.
Text Link Save events to a calendar, search the web, or do a map search directly from information sent through text messages.
Voice Mate™ Voice commands to send text messages/ emails to contacts, add appointments/reminders to the calendar, or complete online searches
Vu: Talk™ Draw and make notes, transfer images, and screen share in real time between compatible devices.*
Notebook Create a shareable notebook with ability to cut and paste pictures, add videos, record voice, and more.
Life Square™ Create a photo journal with select photos, text messages, calls, videos, calendar events, Facebook® posts, and Twitter® tweets.
Polaris® Office 5 PC-like office suite app
Guest Mode™ Create a separate unlock screen pattern for guests with pre-set access and restrictions.**
Plug & Pop Plug in an earphone or USB Cable and related features or apps will appear on the home screen.
Answer Me Accept incoming calls by raising the phone to the ear.
Smart Ringtone Ringtone volume automatically increases in noisy environments.
Smart Screen Display setting keeps the screen active when device detects eye movement.
Privacy Keeper Hide caller information for incoming calls; swipe screen to reveal information.
Quiet Mode Specify times to turn off all sounds except alarm and media.
Notification LED Colored and patterned light for alerts on the Power/Lock Key like alarms, calendar reminders, new messages, missed calls, etc.
* No voice call required. Vu: Talk™ offers simultaneous data and voice sharing when both devices are in 4G LTE coverage or connected to a Wi-Fi network.
** Pattern lock must be enabled to use Guest Mode.
