Screen Size (Inch)
86"
Panel Technology
IPS
Back Light Type
Edge
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
120Hz
Brightness
500nit (Typ.)
Contrast Ratio
1,200:1
Dynamic CR
1,000,000:1
Color Gamut
BT709 95%
Viewing Angle (H x V)
178 x 178
Color Depth (Number of Colors)
8bit(D), 1.07Billion colors
Response Time
8ms (G to G)
Surface Treatment (Haze)
25%
Life time
50,000Hrs (Min.)
Operation Hours (Hours/Day)
24/7
Portait / Landscape
Yes / Yes
HDMI In
Yes(3), 3840x2160@60Hz, HDCP 2.2/1.4
DP In
Yes(1), 3840x2160@60Hz, HDCP 2.2/1.3
RS232C In
Yes (1), 4pin Phone-jack
RJ45(LAN) In
Yes (1)
IR In
Yes (1)
USB In
USB2.0 Type A(2)
Audio Out
Yes (1)
RS232C Out
Yes (1), 4pin Phone-jack
IR Out
No (Support IR daisy chain via RS232C IN/OUT)
Bezel Color
Black
Bezel Width
13.4mm
Weight (Head)
52.7kg(TBD)
Packed Weight
65.5kg(TBD)
Monitor Dimensions (W x H x D)
1928.8 x 1099.8 x 29.7 (without IR, Handle)
Carton Dimensions (W x H x D)
2100 x 1250 x 253(TBD)
Handle
Yes
VESA Standard Mount Interface
600 x 400
Internal Memory (eMMC)
16GB
Wi-Fi/BT (Built-in)
Yes
Temperature Sensor
Yes
Auto Brightness Sensor
Yes(IR)
Acceleration(Gyro) Sensor
Yes
Local Key Operation
Yes
OS Ver. (webOS)
webOS6.0
Local Contents Scheduling
Yes
Group Manager
Yes
USB Plug & Play
Yes
Fail over
Yes
Booting Logo Image
Yes
No Signal Image
Yes
RS232C Sync
Yes
Local Network Sync
Yes
PIP
Yes
PBP
Yes
Screen Share
Yes
Video Tag
Yes
Play via URL
Yes
Screen Rotation
Yes
External Input Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes (Max. 15x15)
Setting Data Cloning
Yes
SNMP
Yes
ISM Method
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
Cisco Certification
Yes (TBD)
Crestron Connected
Yes
Smart Energy Saving
Yes
PM mode
Yes
Wake on LAN
Yes
Network Ready
Yes
Beacon
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
webRTC
Yes
Pro:Idiom
Yes
Operation Temperature
0°C to 40°C
Operation Humidity
10 % to 80 %
Typ.
197W (TBD)
Max.
297W (TBD)
BTU (British Thermal Unit)
672 BTU/Hr(Typ.), 1013 BTU/Hr(Max) (TBD)
Smart Energy Saving (70%)
138W (TBD)
DPM
0.5W
Power off
0.5W
Speaker (Built-in)
Yes (10W X 2)
Safety
CB / NRTL
EMC
FCC Class "B" / CE / KC
ERP / Energy Star
N/A / Yes
ePEAT(US only)
Yes / Carbon "Reducing CO2"
SuperSign CMS
Yes
SuperSign Control+
Yes
SuperSign WB
Yes
SuperSign Cloud
Yes
Mobile CMS
Yes
Connected Care
Yes
OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6EA), Cable Holder(7Pin/1EA)
Optional
Wall Mount (LSW640A/B)
IP Rating
IP5X
Conformal Coating (Power Board)
Yes
