- Pixel Pitch : 0.78 mm
- Screen Size: 136” (Ultra HD)
- Max. Brightness (After Calibration) : 500 nit
- Achieving Deep Black
- Intelligent Processor
- Embedded System Controller and Built-in Speaker
All Spec
INFORMATION
Model name
LAAA007-G2
PHYSICAL PARAMETERS
Pixel Configuration
Micro
Pixel Pitch (mm)
0.78
Screen Resolution (WxH)
3,840 × 2,160
Module Dimensions(WxH,mm)
300 × 112.5
No. of Modules per Screen (WxH)
10 × 15 (Total 150)
Screen Dimensions (W x H x D, mm, including bezel)
3,005x1,742x54.9 (Thickest 57.4)
Screen Surface Area (㎡)
5.06
Weight of the screen
190
Physical Pixel Density (pixels/㎡)
1,638,400
Flatness of Cabinet (mm)
±0.2
Cabinet material
Steel
Service access
Front
OPTICAL SPECIFICATIONS
Max Brightness (After Calibration, nit)
500 / Peak 1,000
Color Temperature
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
95%
Color Uniformity
±0.015 Cx, Cy
Contrast Ratio
25,000 : 1 @ 10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
ELECTRICAL SPECIFICATIONS
Power Consumption (W/Screen, Max.)
1,450
Power Consumption (W/Screen, Avg.)
850
Power Consumption (W/㎡, Max.)
277
Heat Dissipation (BTU/h/Screen, Max.)
4,950
Heat Dissipation (BTU/h/Screen, Avg.)
2,900
Heat Dissipation (BTU/h/㎡, Max.)
950
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
OPERATION SPECIFICATIONS
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0∘ to +40∘
Operating Humidity
10-80% RH
IP rating Front
IP50
IP rating Rear
IP20
STANDARD
Certification
Safety 60950-1,EMC Class A
SPEAKER
Speaker
Built-in (10 W + 10 W)
ENVIRONMENT
Environment
RoHS
CONTROLLER
Controller
Embedded(webOS)
I/O PORT
I/O Port
HDMI(3), DP(1), USB, LAN,RS232C In/Out, IR,Optical Digital Audio Out
