Model name
LAEC015-GN
Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
1.5625
Module Dimensions(WxH,mm)
250 x 281.25
Physical Pixel Density (pixels/㎡)
409,600
Flatness of Cabinet (mm)
±0.2
Cabinet material
Aluminum
Service access
Front
No. of Modules per Screen (WxH)
12x6 (Total 72)
Screen Resolution (WxH)
1,920 x 1,080
Screen Dimensions (W x H x D, mm, including bezel)
3,004.6x1692.1x36.5 (Thickest 70)
Screen Surface Area (㎡)
5.06
Weight of the screen
129
Color Temperature (K)
7300K
Visual Viewing Angle (Horizontal)
160°
Visual Viewing Angle (Vertical)
160°
Brightness Uniformity
98%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3000:1
Processing Depth (bit)
16
Power Consumption (W/Screen, Max.)
2,000
Power Consumption (W/Screen, Avg.)
800
Power Consumption (W/㎡, Max.)
395
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
≥2880
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0℃ to +40℃
Operating Humidity
<90%RH(without condensation)
IP rating Front
IP30
IP rating Rear
IP20
Certification
CE,FCC,ETL,CB
Environment
RoHS, REACH
Controller
Embedded
Speaker
Built-in(9W+9W)
