- Pixel Pitch: 1.90 mm
- Brightness: 800 nit
- Creative LED Screen
- Easy Installation and Maintenance
- Compatibility with LG Software Solutions
All Spec
INFORMATION
Model name
LCCM019-GN
PHYSICAL PARAMETERS
Pixel Configuration
3 in 1
Pixel Pitch (mm)
1.90
Module Resolution (WxH)
168x84
Module Dimensions(WxH,mm)
320x160m
Weight per Module (kg)
0.55
Physical Pixel Density (pixels/㎡)
275,625
Service access
Front
OPTICAL SPECIFICATIONS
Max Brightness (After Calibration, nit)
800
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
97%
Color Uniformity
±0.003CxCy
Contrast Ratio
5,000:1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
ELECTRICAL SPECIFICATIONS
Power Consumption (W/Cabinet, Max.)
36
Power Consumption (W/Cabinet, Avg.)
12.00
Power Consumption (W/㎡, Max.)
720
Heat Dissipation (BTU/h/Cabinet, Max.)
123
Heat Dissipation (BTU/h/Cabinet, Avg.)
41
Heat Dissipation (BTU/h/㎡, Max.)
2,457
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
1,920
OPERATION SPECIFICATIONS
Operating Temperature(℃)
-10℃ to +45℃
Operating Humidity
10~90%RH
IP rating Front
IP30
IP rating Rear
IP30
LED Lifetime (Half brightness)
100,000
STANDARD
Certification
CE, FCC, ETL
ENVIRONMENT
Environment
RoHS, REACH
CONTROLLER
Controller
CVCA
