Model name
LSCB025-RK
Pixel Configuration
Single SMD
Pixel Pitch (mm)
2.5
Module Resolution (WxH)
120x135
Module Dimensions(WxH,mm)
300x337.5
Weight per Module (kg)
0.64
No. of Modules per Cabinet (WxH)
2x1
Cabinet Resolution (WxH)
240x135
Cabinet Dimensions (W x H x D, mm)
600x337.5x34
Cabinet Surface Area (㎡)
0.2
Weight per Cabinet (kg/unit)
5.3
Weight per Square Meter (kg/㎡)
26.17
Physical Pixel Density (pixels/㎡)
160,000
Flatness of Cabinet (mm)
±0.1
Cabinet material
Die-casting Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
800
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
0.97
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000:1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
100
Power Consumption (W/Cabinet, Avg.)
34
Power Consumption (W/㎡, Max.)
494
Heat Dissipation (BTU/h/Cabinet, Max.)
341
Heat Dissipation (BTU/h/Cabinet, Avg.)
116
Heat Dissipation (BTU/h/㎡, Max.)
1,685
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Operating Temperature(℃)
-10℃ to +45℃
Operating Humidity
0~80%RH
IP rating Front
IP30
IP rating Rear
IP30
LED Lifetime (Half brightness)
100,000
Certification
CE, FCC, ETL, EMC Class-B, Fire Protection
Environment
RoHS, REACH
Controller
CVCA
90 degree corner cut
O
