Model name
GMBD035-GN4
Pixel Configuration
4 in 1 SMD
Pixel Pitch (mm)
35.00
Module Resolution (WxH)
1x80
Module Dimensions(WxH,mm)
18x2,800
Weight per Module (kg)
0.52
No. of Modules per Cabinet (WxH)
8x1
Cabinet Resolution (WxH)
8x80
Cabinet Dimensions (W x H x D, mm)
280x2,800
Cabinet Surface Area (㎡)
0.784
Weight per Cabinet (kg/unit)
6.2
Weight per Square Meter (kg/㎡)
8.0
Physical Pixel Density (pixels/㎡)
816
Cabinet material
Plastic body and silicon cable
Service access
Front and Rear
Max Brightness (After Calibration, nit)
7,500
Color Temperature (K)
18,000-25,000
Visual Viewing Angle (Horizontal)
120
Visual Viewing Angle (Vertical)
120
Brightness Uniformity
90%
Contrast Ratio
20,000:1
Processing Depth (bit)
12 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
640
Power Consumption (W/Cabinet, Avg.)
213
Power Consumption (W/㎡, Max.)
816
Heat Dissipation (BTU/h/Cabinet, Max.)
2,184
Heat Dissipation (BTU/h/Cabinet, Avg.)
727
Heat Dissipation (BTU/h/㎡, Max.)
2,784
Power Supply (V)
15
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
20,000
Operating Temperature(℃)
-40℃ to +60℃
Operating Humidity
10~90%RH
IP rating Front
IP66
IP rating Rear
IP66
LED Lifetime (Half brightness)
100,000
Certification
CE, FCC, cTUVus, CB
Environment
RoHS, REACH
Controller
CVBA
90 degree corner cut
Yes
