UH5F-H Series

55UH5F-H

Key Features

Brightness(Typ.) : 500 cd/m²
Surface Treatment (Haze) : 28%
Bezel : 9.9 mm (T/R/L), 14.4 mm (B)
Depth : 39.9 mm
Interface : HDMI(3)/DP/DVI-D/USB 2.0/ RS232C/ RJ45/ Audio/ IR
30º Tilting Installation

All Spec

SOUND

Speaker (Built-in): YES (10W x 2)

LANGUAGE

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic

ACCESSORY

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender

Optional: Stand(ST-653T), OPS Kit(KT-OPSF)

POWER

Power Supply: AC 100-240V~, 50/60Hz

Power Type: Built-in Power

ENVIRONMENT CONDITIONS

Operation Humidity: 10 % to 80 %

Operation Temperature: 0 °C to 40 °C

OPS COMPATIBILITY

OPS Power Built-in: NO

OPS Type compatible: YES (Piggyback)

CERTIFICATION

EMC: FCC Class "A" / CE / KC

ePEAT(US only): NO

ERP / Energy Star: YES(NewErP) / YES

Safety: CB / NRTL

MECHANICAL SPECIFICATION

Weight (Head): 19.0Kg

Bezel Color: Black

Bezel Width: T/R/L: 9.9mm, B: 14.4mm

Carton Dimensions (W x H x D): 1360.0 x 835.0 x 175.0mm

Handle: NO

Monitor Dimensions (W x H x D): 1234.4 x 720.9 x 39.9mm (with LG Logo)

Monitor Dimension with Stand (W x H x D): 1234.4 x 770.7 x 290.0mm

Packed Weight: 24.2Kg

VESA Standard Mount Interface: 300 x 300 mm

Weight (Head+Stand): 19.6Kg

POWER CONSUMPTION

BTU (British Thermal Unit): 358 BTU/Hr(Typ.), 495 BTU/Hr(Max.)

DPM: 0.5W

Max.: 145W

Power off: 0.5W

Smart Energy Saving (70%): 84W

Typ.: 105W

PANEL

Aspect Ratio: 16:9

Back Light Type: Edge

Brightness: 500nit (Typ.)

Color Depth (Number of Colors): 1.07 Billion colors

Color Gamut: BT709 95%

Contrast Ratio: 1,100:1

Dynamic CR: 1,000,000:1

Life time: 50,000Hrs (Min.)

Native Resolution: 3840 x 2160 (UHD)

Operation Hours (Hours/Day): 24/7

Panel Technology: IPS

Portait / Landscape: YES / YES

QWP (Quarter Wave Plate): N/A

Refresh Rate: 60Hz

Response Time: 8ms (G to G)

Screen Size (Inch): 55

Surface Treatment (Haze): Haze 28%

Transparency: N/A

Viewing Angle (H x V): 178º x 178º

CONNECTIVITY

Audio In: YES

Audio Out: YES

Daisy Chain: NO

DP In: YES (HDCP 2.2/1.3)

DP Out: YES

DVI-D In: YES (HDCP 1.4)

External Speaker Out: NO

HDMI In: YES (3ea)

HDMI In (HDCP Ver.): 2.2/1.4

HDMI Out: NO

IR In: YES

IR Out: NO

RGB In: NO

RJ45(LAN) In: YES (1ea)

RJ45(LAN) Out: NO

RS232C In: YES

RS232C Out: YES

Touch USB: NO

USB In: USB2.0 Type A (1ea)

SPECIAL FEATURE

Conformal Coating (Power Board): YES

Direct Sunlight: N/A

IP Rating: IP5X

Overlay Touch Compatibility: N/A

Power Protection: N/A

Smart Calibration: N/A

Tilt (Face down): Max. 30 degree

Tilt (Face up): N/A

SOFTWARE COMPATIBILITY

Connected Care: YES

Mobile CMS: YES

Promota: YES

SuperSign Cloud: NO

SuperSign CMS: YES

SuperSign Control+: YES

SuperSign WB: YES

FEATURE - HARDWARE

Acceleration(Gyro) Sensor: YES

Auto Brightness Sensor: YES

BLU Sensor: NO

Current Sensor: NO

FAN (Built-in): NO

Humidity Sensor: NO

Internal Memory (eMMC): 8GB

Local Key Operation: YES

Pixel Sensor: NO

Power Indicator: NO

Proximity Sensor: NO

Temperature Sensor: YES

Wi-Fi/BT (Built-in): YES

FEATURE - SOFTWARE

Auto Set ID: YES

Backlight Sync: NO

Beacon: YES

Booting Logo Image: YES

Brightness Compensation: NO

Cisco Certification: YES

Control Manager: YES

Crestron Connected: YES

External Input Rotation: YES

Fail over: YES

Gapless Playback: YES

Group Manager: YES

HDMI-CEC: YES

ISM Method: YES

Local Contents Scheduling: YES

Local Network Sync: YES

Network Ready: YES

No Signal Image: YES

OS Ver. (webOS): webOS 4.1

PBP: YES (4PBP)

PIP: YES

Play via URL: YES

PM mode: YES

Pro:Idiom: YES

RS232C Sync: YES

Scan Inversion: NO

Screen Rotation: YES

Screen Share: YES

Setting Data Cloning: YES

SI Server Setting: YES

Smart Energy Saving: YES

SNMP: YES

Status Mailing: YES

Tile Mode Setting: YES

USB Plug & Play: YES

Video Tag: YES (4 Video Tag)

Wake on LAN: YES

webRTC: YES

W/B Setting by Grey scale: NO
