- Brightness : 390 nit (w/o Glass, Typ.)
- Multi Touch Point : 20 Points (Max.)
- Interface : HDMI (3), RGB (1), Audio In (1), RS-232C In (1), RJ45 (1), USB 3.0 Type A (3), USB 2.0 Type A (1), USB 3.1 Type C (1), Audio Out / Optical Output, Touch USB (2)
All Spec
LANGUAGE
OSD
English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Russian, Spanish, Swedish, Tßrkçe, Ukrainian, Traditional Chinese, Hungarian, Latvian, Thai
POWER
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-in Power
SOUND
Speaker (Built-in)
YES (16W x 2)
ACCESSORY
Basic
Power Cord 3M*1, USB Cable (Type A-Type B) 5M*1, HDMI Cable 3M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
Optional
NO
ENVIRONMENT CONDITIONS
Operation Humidity
10 % to 80 %
Operation Temperature
0 °C to 40 °C
OPS COMPATIBILITY
OPS Power Built-in
YES
OPS Type compatible
YES (Slot)
CERTIFICATION
EMC
FCC Class "A" / CE
ERP / Energy Star
YES / NO
Safety
CB / NRTL
DEDICATED FEATURE - TOUCH
Accuracy (Typ.)
Âą1mm
Available Object Size for Touch
Ă2 mm â
Interface
USB3.0
Multi Touch Point
Max. 20 Points
Operating System Support
Windows 7/8/10/XP/Linux/Mac/Android (Windows XP/Linux/Mac Support one point touch)
Protection Glass Thickness
4mm (Anti-Glare)
Protection Glass Transmission
0.87
Response Time ('Paint' app on Windows 10 PC)
10ms â
MECHANICAL SPECIFICATION
Weight (Head)
103.6Kg
Bezel Color
Black
Bezel Width
T/R/L/B : 29.6/26.6/26.6/44.5mm
Carton Dimensions (W x H x D)
2406 x 1474 x 280mm
Handle
YES
Monitor Dimensions (W x H x D)
2244.7 x 1323.2 x 89.5mm
Packed Weight
126.5Kg
VESA Standard Mount Interface
800 x 600 mm
POWER CONSUMPTION
BTU (British Thermal Unit)
1570 BTU/Hr(Typ.), 2150 BTU/Hr(Max.)
DPM
0.5W
Max.
630W
Power off
0.5W
Typ.
460W
PANEL
Aspect Ratio
16:9
Back Light Type
Direct
Brightness
390nit (Typ., without Glass)
Color Depth (Number of Colors)
1.07 Billion colors
Color Gamut
NTSC 72%
Contrast Ratio
1,200:1
Dynamic CR
NO
Life time
30,000Hrs (Min.)
Native Resolution
3840 x 2160 (UHD)
Operation Hours (Hours/Day)
16/7
Panel Technology
IPS
Portait / Landscape
NO / YES
Refresh Rate
60Hz
Response Time
8ms (G to G)
Screen Size (Inch)
98
Surface Treatment (Haze)
Haze 28%
Viewing Angle (H x V)
178Âş x 178Âş
CONNECTIVITY
Audio In
YES
Audio Out
YES
DP In
NO
DP Out
NO
DVI-D In
NO
External Speaker Out
NO
HDMI In
YES (3ea)
HDMI In (HDCP Ver.)
2.2/1.4
HDMI Out
YES
IR In
NO
RGB In
YES
RJ45(LAN) In
YES (1ea)
RJ45(LAN) Out
YES
RS232C In
YES
RS232C Out
NO
Touch USB
USB2.0 Type B (2ea)
USB In
USB3.0 Type A (4ea), USB2.0 Type A (1ea), USB Type C (1ea)
SPECIAL FEATURE
Conformal Coating (Power Board)
YES
DEDICATED FEATURE - CREATE BOARD
Bluetooth
Bluetooth 4.0
CPU
Quad core A73
GPU
Mail G52 Multicore 2
LAN
Gigabit LAN
Memory(RAM)
4GB
OS ver. (Android)
Android 9
Storage
32GB
Wi-Fi
802.11a/b/g/n/ac
SOFTWARE COMPATIBILITY
Connected Care
YES
FEATURE - HARDWARE
Auto Brightness Sensor
NO
Internal Memory (eMMC)
32GB
Local Key Operation
YES
Power Indicator
YES
Temperature Sensor
NO
Wi-Fi/BT (Built-in)
YES
FEATURE - SOFTWARE
Booting Logo Image
NO
Crestron Connected
NO
HDMI-CEC
NO
Network Ready
NO
PBP
NO
PIP
NO
PM mode
NO
Screen Share
YES
Setting Data Cloning
NO
Smart Energy Saving
NO
Wake on LAN
NO
