Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
1.5625
Module Dimensions (W x H, mm)
250x281.25
Screen Resolution (WxH)
1,920x1,080
Screen Dimension (W x H x D,mm)
3,004.6x1692.1x36.5 (Thickest 70)
No. of Modules per Screen (W x H)
12x6 (Total 72)
Screen Surface Area (㎡)
5.06
Physical Pixel Density (pixels/m²)
409,600
Flatness of Cabinet
±0.2 mm
Cabinet Material
Aluminum
Service Access
Front
Min. Brightness (After Calibration)
500
Color Temperature
7300K
Visual Viewing Angle (Horizontal/Vertical)
160° x 160°
Brightness Uniformity
98%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3000:1
Processing Depth (bit)
16
Power Consumption (W/Screen, Max.)
2,000
Power Consumption (W/Screen, Avg.)
800
Power Consumption (W/m², Max.)
395
Power Consumption (BTU/h/cabinet, Max.)
6,824
Power Consumption (BTU/h/cabinet, Avg.)
2,730
Power Consumption (BTU/h/㎡, Max.)
1,348
Power Supply (V)
100 to 240
Frame Rate (Hz)
50/60
Refresh Rate (Hz)
≥2880
Operating Temperature (°C)
0℃ to +40℃
Operating Humidity
<90%RH(without condensation)
IP rating Front / Rear
IP30 / IP20
Speaker
Built-in(9W+9W)
Certification
CE,FCC,ETL,CB
Environment
RoHS, REACH
Controller
Embedded
