Pixel Configuration
1R, 1G, 1B (Chip on Board)
Pixel Pitch(mm)
0.93
Module Resolution (WxH)
160 x 180
Module Dimensions(WxH,mm)
150 x 168.8
Weight per Module (g)
150
No. of Modules per Cabinet (WxH)
8 (4x2)
Cabinet Resolution (WxH)
640 x 360
Cabinet Dimensions (W x H x D, mm)
600 x 337.5 x 44.9
Cabinet Surface Area (㎡)
0.203
Weight per Cabinet (kg/Cabinet)
7.0
Weight per Square Meter (kg/m²)
34.6
Physical Pixel Density (pixels/m²)
1,137,778
Flatness of Cabinet (mm)
±0.5 mm
Cabinet Material
Die-casting Aluminum
Service access
Front and Rear (Module : Front Only)
Brightness (Peak/Max, After Calibration)
1,200 / 600
Color Temperature (Default, Adjustable²))
7,300/3,200~9,300K (Adjustable via LG LED Assistant on PC)
Visual Viewing Angle (Horizontal)
160°
Visual Viewing Angle (Vertical)
160°
Brightness Uniformity
95%
Color Uniformity
±0.02Cx, Cy
Contrast Ratio (10 lux)
150,000:1
Processing Depth (bit)
20
HDR Compatibility
HDR10, HDR10 Pro1)
Driver-IC Type
Common Cathode
Power Consumption (W/Cabinet, Max.)
125
Power Consumption (W/Cabinet, Avg.)
85
Power Consumption (W/㎡, Max.)
617
Power Consumption (BTU/h/Cabinet, Max.)
427
Power Consumption (BTU/h/Cabinet, Avg.)
290
Power Consumption (BTU/h/m², Max.)
2,108
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature(℃)
0∘ to +40∘
Operating Humidity
10-80 %RH
IP Rating Front
IP50
IP Rating Rear
IP20
Certification
Safety 60950-1, EMC Class A, BS476 Part 7 Class 1
Environment
RoHS
Optional Accessory
Wall Mount Kit, Frame Kit
Controller
CSAB-009X
