- Safe Plus Internal Insulation to Provide Cleaner, Fresher Airflow
- Powerful 5-Step Air Purification System for Healthier Indoor Spaces (Optional)
- Smart Remote Control with ThinQ™, Allowing Maximized Comfort (Optional)
- Flexible, Easy Installation
All Spec
CAPACITY
Cooling¹ (Min. ~ Rated ~ Max.) (kW)
4.68~9.40~11.10
Cooling¹ (Min. ~ Rated ~ Max.) (Btu/h)
16,030~32,000~38,000
Cooling² (Min. ~ Rated ~ Max.) (kW)
4.68~8.20~11.10
Cooling² (Min. ~ Rated ~ Max.) (Btu/h)
16,030~28,000~38,000
Heating (Min. ~ Rated ~ Max.) (kW)
3.99~9.95~10.80
Heating (Min. ~ Rated ~ Max.) (Btu/h)
13,640~34,000~37,000
POWER INPUT
Cooling¹ (Rated) (kW)
2.58
Cooling² (Rated) (kW)
3.22
Heating (Rated) (kW)
2.85
EER / COP
Cooling¹ / Heating (W / W)
12.40 / 3.50
OUTDOOR UNIT
Power Supply (V , Ø , Hz)
220-230-240, 1, 50/60
Dimensions (W x H x D) (mm)
950 x 834 x 330
Net Weight (kg (lbs))
56.6
Compressor Type
Twin Rotary
Refrigerant Type
R410A
Fan Air Flow Rate (m3/min x No.)
60 x 1
Fan Motor Type
BLDC
Sound Pressure Level Cooling (Rated) (dB(A))
51.00
Sound Pressure Level Heating (Rated) (dB(A))
53.00
Piping Connections Liquid (Outer Dia.) (mm (inch))
Φ9.52 (3/8)
Piping Connections Gas (Outer Dia.) (mm (inch))
Φ15.88 (5/8)
Piping Length (Max.) (m (ft))
50
Maximum Height Difference Outdoor Unit ~ Indoor Unit (Max.) (m (ft))
30.00
INDOOR UNIT
Power Supply (V , Ø , Hz)
220-230-240, 1, 50/60
Dimensions Body (W x H x D) (mm)
840 x 246 x 840
Net Weight (kg (lbs))
25.5
Air Flow Rate (H / M / L) (m3/min)
23.0 / 21.0 / 19.0
Fan Motor Type
BLDC
Sound Pressure Level Cooling (H / M / L) (dB(A))
40.0 / 38.0 / 36.0
Sound Pressure Level Heating (H / M / L) (dB(A))
40.0 / 38.0 / 36.0
