WH16NS60

Key features

  • Silent Play
  • Reduces Noise from Disc Spin During Movie Playback
  • Jamless Play
  • Max. 16X BD-R Read and Write Capability
  • Max. 16X DVD±R Write Speed
Specifications
  • ACCESS TIME
  • COMPLIANCE
  • Contents
  • HOST INTERFACE
  • OPERATING SYSTEMS
  • Other Features
  • SIZE & WEIGHT
  • SOFTWARE
  • SUSTAINED TRANSFER RATE
  • TRANSFER RATES-READ
  • TRANSFER RATES-WRITE
  • Type
  • UHD SYSTEM REQUIREMENTS
  • Warranty/UPC
  • See All
    • ACCESS TIME
    BD-Rom
    180ms typ.
    Buffer Size
    4MB Buffer Under-run prevention function embedded
    CD-ROM
    150ms typ.
    DVD-ROM
    160ms typ.
    ACCESS TIME
    BD-Rom
    180ms typ.
    Buffer Size
    4MB Buffer Under-run prevention function embedded
    CD-ROM
    150ms typ.
    DVD-ROM
    160ms typ.
    COMPLIANCE
    BSMI
    No
    CB & IEC60825-1 Report
    No
    CB & IEC60825-1/ EN 60825-1
    No
    CE
    No
    CNAS
    No
    CSA
    No
    CU
    No
    C-UL
    CSA C222 No. 60950-1 Second Edition
    EMC/EMI
    CE Marking_RCM_BSMI_FCCI_KC_CU_FCC Part 15 Class B Digital Device_ICES-003 Digital Apparantus
    FCC
    No
    FDA
    No
    KC
    No
    Laser Safety
    Class 1 laser product comply with DHHS rules 21 CFR Subchapter J Class 1 laser product to EN60825-1 / IEC 60825-1
    RCM
    No
    RoHS
    Yes
    Safety UL
    UL 60950-1 Second Edition
    SEMKO
    No
    SONCAP
    No
    TUV
    No
    TUV / SEMKO
    EN 60950-1 / EN60825-1
    UL
    No
    VCCI
    No
    Contents
    External Blu-ray / DVD Writer
    No
    Label Print
    No
    Norton internet Security (60 days)
    No
    Power Backup
    No
    Power2Go
    No
    Slim DVD Writer
    No
    Slim Portable Blu-ray Writer
    No
    Slim Portable DVD Writer
    No
    Ultra Slim BD-ROM / DVD Writer
    No
    USB 2.0 Cable
    No
    USB 3.0 Cable
    No
    YouCam
    No
    HOST INTERFACE
    Internal (Drive)
    SATA
    SATA
    No
    USB
    No
    OPERATING SYSTEMS
    OPERATING SYSTEMS
    Windows 10, Windows 7, Windows 8, Windows 8.1
    Other Features
    Jamless Play
    Yes
    Silent Play
    Yes
    TV Connectivity (Function needs to be added)
    No
    SIZE & WEIGHT
    Dimensions (W x H x D)
    5.7" x 1.6" x 6.5" ( W/O Bezel )
    SOFTWARE
    CyberLink PowerBackup
    No
    CyberLink PowerDVD
    No
    CyberLink PowerProducer
    No
    CyberLinkPower2Go
    No
    SUSTAINED TRANSFER RATE
    BD-Rom
    53.94 Mbytes/s (12x) max.
    CD-ROM
    7.2 MB/s (48x) max.
    DVD-ROM
    22.16 Mbytes/s (16x) max.
    TRANSFER RATES-READ
    DVD+RW
    12x CAV
    BDMV (AACS Compliant Disc) (SL/DL)
    12x / 8x CAV
    BDMV(UHD)(DL / TL)
    8x CAV / 8x CAV
    BD-R (SL)
    12x CAV / 8x CAV
    BD-R (SL/LTH)
    8x CAV
    BD-R (TL/QL)
    6x / 6x CAV
    BD-RE (SL/DL)
    10x CAV / 6x CAV
    BD-RE (TL)
    4x CLV
    BD-ROM (SL/DL)
    12x CAV / 8x CAV
    CD-DA
    40x CAV
    CD-R/RW/ROM
    48x / 40x / 48x CAV
    DVD-R (SL/DL)
    16x / 12x CAV
    DVD-RAM
    5x CLV
    DVD-ROM (SL/DL)
    16x / 12x CAV
    DVD-RW
    12x CAV
    DVD-Video (CSS Compliant Disc) (SL/DL)
    12x / 8x CAV
    TRANSFER RATES-WRITE
    DVD+R (DL)
    8x ZCLV
    DVD+R (SL)
    16x CAV
    DVD+RW
    8x ZCLV
    BD-R (LTH)
    8x PCAV
    BD-R (SL)
    16x ZCLV
    BD-R (TL)
    8x ZCLV
    BD-R(DL)
    12x CAV
    BD-R(QL)
    6x ZCLV
    BD-RE (SL/DL/TL)
    2x CLV
    CD-R
    48x CAV
    CD-RW
    24x ZCLV
    DVD-R (DL)
    8x ZCLV
    DVD-R (SL)
    16x CAV
    DVD-RAM
    5x CLV
    DVD-RW
    6x CLV
    M-DISC BD (BD-R SL / DL / TL)
    4x CLV / 6x PCAV / 4x CLV
    M-Disc DVD(DVD+R)
    4x CLV
    Type
    Blu-ray / DVD Writer
    Type
    External
    No
    Internal
    No
    UHD SYSTEM REQUIREMENTS
    Chipset
    Intel SGX* / HDMI 2.0a / HDCP* 2.2 & 1.4 Support
    CPU
    Intel 7th Gen. Kabylake Core i3 or higher
    Display
    UHD (3, 840 x 2, 160 pixel) Resolution / HDMI 2.0a (HDR*) / HDCP* 2.2 & 1.4 Support
    GPU
    Intel HD Graphics 630 or higher
    Network
    Need To Network Access
    O/S
    Windows 10
    RAM
    Minimum 6GB
    Warranty/UPC
    UPC
    719192625198
    Features
    Superior data protection with M DISC Support
    BDX Support Ultimate Capacity
    16x BD R Writing

    The M-DISC™ uses a patent rock-like recording surface instead of organic dye to etch your data onto a disc. The M-DISC has been tested and proven to outlast standard DVDs currently on the market.

    Three Layer BDXL-R/BDXL RE discs offer 100GB capacity while quad layer BDXL-R discs boast 128GB storage capacity on a single disc. It is equivalent of 27 standard DVDs or 5 single layer Blu-ray discs.

    Capture all the excitement of Blu-ray with the 16x BD-R writing capability. Plus, now you can store more data on to BDXL™ discs.
