LG LSG4513BD 6.3 cu. ft. Gas Single Oven Slide-in Range with ProBake Convection® and EasyClean®
6.3 cu. ft. Gas Single Oven Slide-in Range with ProBake Convection® and EasyClean®
6.3 cu. ft. Gas Single Oven Slide-in Range with ProBake Convection® and EasyClean®
6.3 cu. ft. Gas Single Oven Slide-in Range with ProBake Convection® and EasyClean®
DISCONTINUED
LG LSG4513BD 6.3 cu. ft. Gas Single Oven Slide-in Range with ProBake Convection® and EasyClean®

6.3 cu. ft. Gas Single Oven Slide-in Range with ProBake Convection® and EasyClean®

LSG4513BD

Key features

  • 6.3 cu. ft. Large Capacity
  • PrintProof™ Finish
  • EasyClean®
  • ProBake Convection®
  • UltraHeat™ 18.5K BTU Power Burner

Specifications

Download Spec Sheet
  • CONTROLS
  • POWER/RATINGS
  • COOKTOP
  • WARRANTY/UPC
  • OVEN FEATURES
  • SUMMARY
  • CAPACITY
  • ACCESSORIES
  • APPEARANCE
  • DIMENSIONS/CLEARANCES/WEIGHT
  • See All
  • CONTROLS
    Automatic Safety Shut-Off
    After 12 hours
    Display
    VFD
    Temperature Unit of Measure
    ˚F or ˚C
    Oven Control Type
    Glass Touch
    Clock
    12 hr or 24 hr (option)
    Cooktop Control Type
    Front Tilt-Control Knobs
    Certified Sabbath Mode:
    No
    Cooking Complete Reminder Volume
    1. High 2. Low 3. Mute
    CONTROLS
    Automatic Safety Shut-Off
    After 12 hours
    Display
    VFD
    Temperature Unit of Measure
    ˚F or ˚C
    Oven Control Type
    Glass Touch
    Clock
    12 hr or 24 hr (option)
    Cooktop Control Type
    Front Tilt-Control Knobs
    Certified Sabbath Mode:
    No
    Cooking Complete Reminder Volume
    1. High 2. Low 3. Mute
    POWER/RATINGS
    Requirements
    120 VAC
    Amp Rating at 240V
    539W
    Amp Rating at 208V
    4.2A
    COOKTOP
    Center (Warming Zone) (BTU):
    10,000 (Oval-Burner)
    Burner/BTU - Right Rear
    5,000 BTU
    Burner/BTU - Left Front
    12,000 BTU
    Burner/BTU - Right Front
    18,500 BTU
    Burner/BTU - Left Rear
    9,100 BTU
    WARRANTY/UPC
    Limited Warranty
    1 Year Parts & Labor
    UPC
    48232335460
    OVEN FEATURES
    GoCook Smart Oven Light
    Yes (1 Light)
    Convection Conversion
    Yes
    Door Lock
    Yes
    Configuration
    Single Oven
    Broil Element (BTUh)
    15000/12500
    Convection Burner (BTU/h)
    19000 / 17000 (LNG/LPG)
    ProBake Convection®
    Yes
    Self Clean
    Yes
    No. of Rack Positions
    7
    Oven Modes
    Bake, Broil High, Broil Low, Conv. Bake, Conv. Roast, Pizza, Warm, Proof, EasyClean, SelfClean, Remote Start, Delay Timed Cook, Timed Cook
    Oven Type
    Single Oven
    Oven Cooking System
    Convection
    Slide-In
    Yes
    SUMMARY
    Fuel Type
    Electric
    Self + EasyClean®
    Yes
    CAPACITY
    Oven Capacity (cu. ft.)
    6.3
    ACCESSORIES
    Standard Rack
    3
    Conversion Kit
    Yes
    Spray Bottle
    Yes
    Scouring Pad
    Yes
    Griddle Plate
    Yes
    APPEARANCE
    Handle/Knobs
    Stainless-Steel Finish (AI), BLK Stainless Steel
    Oven Door Feature
    WideView™ Window
    All Available Colors
    Stainless Steel, Black Stainless Steel
    Cooktop Finish
    Stainless Steel
    DIMENSIONS/CLEARANCES/WEIGHT
    Carton Dimensions (in) (W x H x D)
    32 1/2" x 44" x 30 1/2"
    Weight (Product)
    189 lbs
    Drawer Dimensions (in) (W x H x D)
    22 3/16" x 4 1/2" x 16 3/8"
    Shipping Weight (lbs)
    210 lbs
    Overall Width (in)
    29 7/8"
    Oven Interior Dimensions (in) (W x H x D)
    24 7/8" x 21 3/8" x 20"
    Height to Cooking Surface (in)
    36"
    Depth (including handle)
    28 15/16"
    Cabinet Width (in)
    30"
    Overall Height (in) - including backguard
    37 7/8”
