Top Control Smart wi-fi Enabled Dishwasher with QuadWash™ and TrueSteam®
DISCONTINUED
Top Control Smart wi-fi Enabled Dishwasher with QuadWash™ and TrueSteam®
LDP6809BD
Key features
- QuadWash™ System
- TrueSteam®
- 3rd Rack
- PrintProof™ Finish
- LoDecibel™ Operation (44dB)
- ThinQ® Technology
Specifications
CAPACITY
CERTIFICATIONS
DIMENSIONS/CLEARANCES/WEIGHT
FEATURES
LIMITED WARRANTY
POWER RATINGS
RACKS AND BASKETS
STYLE AND DESIGN
SUMMARY
DISHWASHER THINQ® SMART FEATURES
See All
CAPACITY
Lower Rack Dish Height Limit
12.5"
Total Place Settings
15
Upper Rack Dish Height Limit
7.1"
CAPACITY
Lower Rack Dish Height Limit
12.5"
Total Place Settings
15
Upper Rack Dish Height Limit
7.1"
CERTIFICATIONS
NSF
No
DIMENSIONS/CLEARANCES/WEIGHT
Carton Dimensions (in) (W x H x D)
28" x 34 7/10" x 29 3/5"
Depth with Door Closed with Handle (in)
24.6"
Depth with Door Open (in)
50.5"
Product Dimensions (in) (W x H x D)
23 3/4" x 33 3/5" x 24 3/5"
Product Weight (lbs)
84.7 lbs
Shipping Weight with Carton (lbs)
96.8 lbs
FEATURES
Heated Dry Option
No
3-Stage Filtration System
Yes
ADA Compliant
No
Detergent and Rinse-Aid Dispenser
Yes
Drying System
Dynamic Dry™
End of Cycle Indicator
Beeper + END Indication on Display
Hidden Water Heater
Yes
Hybrid Condensing Drying System
Yes
Inverter Direct Drive Motor
Yes
LoDecibel™ Quiet Operation
44 dBA
Multi-Level (5) Water Direction
No
Number of Options
9 (Dual Zone, Half Load, Energy Saver, Steam, High Temp, Extra Dry, Delay Start, Control Lock, Night Dry)
Number of Spray Arms
3 (Top, Upper, Lower)
Number of Wash Cycles
10 (Auto, Heavy, Delicate, Refresh, Normal, Turbo, Download Cycle, Machine Clean, Rinse, Express)
Leak Detection
Yes
QuadWash®
Yes
Rinse-Aid Indicator
Yes
Safety Float Switch (Leaks)
Yes
SenseClean™ Wash System
Yes
Soil (Turbidity) Sensor
Yes
Time Remaining Indicator
Yes
TrueSteam®
Yes
Variable Spray Intensities
Yes
Vario Wash
Yes
Dynamic Heat Dry™
No
1-Hour Wash & Dry
No
LIMITED WARRANTY
Control Board and Rack Parts
5 Years
Direct Drive Motor
10 Years
Labor
1 Year
Parts
1 Year
Stainless Steel Door Liner or Tub
1 Year
UPC
048231341158
POWER RATINGS
CEE Tier
1
ENERGY STAR® Qualified
Yes
Energy Use (kWh/Year)
258 kWh/Year
Water Factor (WF)
2.9
RACKS AND BASKETS
3rd Rack (Fixed)
Yes
BPA-Free Nylon Coated Racks and Tines
Yes
Cup Rack
Yes
Cutlery Baskets
Yes
EasyRack™ Plus System
Yes
Fold Down Tines
Yes (Half Fold on Upper & Half (Smart), Half (Normal) Fold on Lower)
Glide Rail
No
Height Adjustable Middle Rack
No
Height Adjustable Upper Rack
Yes
Height-Adjustable 3rd Rack
No
Rack Handle
Yes
Stemware Holder
Yes
Wheel Bearing
No
STYLE AND DESIGN
All Available Colors
PrintProof™ Black Stainless Steel, PrintProof™ Stainless Steel
Control Panel Location
Top Control
Electronic Controls
Fully Integrated Control Panel
Fingerprint Resistant
Yes
Handle
Pocket Handle
LED Tub Light
No
PrintProof™ Finish
Yes
Tub Light
No
Tub Material
NeveRust™ Stainless Steel
SUMMARY
Series
LG
DISHWASHER THINQ® SMART FEATURES
Monitor Cycle Time
No
ThinQ Care™
Yes
NFC Tag On
No
Remote Control
No
Remote Monitoring
No
SmartDiagnosis™
Yes
SmartThinQ®
Yes
ThinQ® Smart Technology
Yes
wi-fi Enabled
Yes
Works with
Amazon Alexa, Google Assistant
ThinQ UP™
No
Community Q&A
Discover the Top Control Smart wi-fi Enabled Dishwasher with QuadWash™ and TrueSteam® (LDP6809BD).
