3D-Capable Blu-ray Disc™ Home Theater System with Smart TV and Wireless Speakers
DISCONTINUED
3D-Capable Blu-ray Disc™ Home Theater System with Smart TV and Wireless Speakers
LHB976
Key features
- Smart TV Access
- 3D Blu-ray Disc™ & Blu-ray Disc™ 1080p Playback
- Wi-Fi® Capable
- DLNA Certified
Specifications
AMPLIFIER / SPEAKER
POWER
FRONT AUDIO / VIDEO INPUTS & OUTPUTS
SUMMARY
CONVENIENCE FEATURES
SIZE & WEIGHT
REAR AUDIO / VIDEO INPUTS & OUTPUTS
VIDEO CAPABILITIES
TUNER
SPECIAL FEATURES
INCLUDED ACCESSORIES
AUDIO CAPABILITIES
See All
AMPLIFIER / SPEAKER
Output Power - Front
180W x 2 (4Ω, Peak)
Output Power - Center
180W (4Ω, Peak)
Output Power - Rear
180W x 2 (4Ω, Peak)
Output Power - Subwoofer
200W (4Ω, Peak)
Center Speaker Type
Satellite
Front Speaker Types
Tall-boy
Rear Speaker Types
Satellite
Subwoofer Speaker Type
Passive
AMPLIFIER / SPEAKER
Output Power - Front
180W x 2 (4Ω, Peak)
Output Power - Center
180W (4Ω, Peak)
Output Power - Rear
180W x 2 (4Ω, Peak)
Output Power - Subwoofer
200W (4Ω, Peak)
Center Speaker Type
Satellite
Front Speaker Types
Tall-boy
Rear Speaker Types
Satellite
Subwoofer Speaker Type
Passive
POWER
Power Requirements
AC 120 V, 60Hz
Power Consumption
150W
FRONT AUDIO / VIDEO INPUTS & OUTPUTS
USB 2.0 In
1
Portable Audio In
1
iPod/iPhone Dock
1
SUMMARY
Disc Playback Capability
Blu-ray Disc™, BD-R/RE, DVD-Video, DVD±R, DVD-RW, DVD+RW, Audio CD, CD-R/RW
Blu-ray Support
Yes
Full HD 1080p resolution
Yes
Upscale Standard DVDs
Yes
Wi-Fi Connectivity
Yes
No. of HDMI Ports
3 (2 In / 1 Out)
Disc Capacity
1
Video Content Formats
MPEG4 AVC, HP@L4.1, MPEG2, HP@ML, SMPTE VC1, AP@L3, AVCHD
Surround Sound
5.1 Channel
Total Output Power
1100W (4Ω, Peak)
Video, Pictures and Music via USB 2.0
Yes
SimpLink™ connectivity
Yes
Limited Waranty
1 Year Parts/90 Days Labor
Home Link Playable Content Format
DivX®/DivX HD, MPEG2 TS/PS, MPEG1 SS, XVID, MKV, AVI, WMA, MP3, AC3, AAC, JPEG
CONVENIENCE FEATURES
Sleep
Yes
Screen Saver
Yes
Parental Lock
Yes
Repeat
Yes
A-B Repeat
Yes
Speaker/Woofer Level Trim
Yes
Speaker Distance (Channel Delay)
Yes
Mute
Yes
Quick Loading
Yes
Scan (fwd/rev)
Yes
Skip (fwd/rev)
Yes
Slow (fwd/rev)
Yes
Test Tone
Yes
SIZE & WEIGHT
Main Unit Dimensions (WxHxD)
16.9" x 2.3" x 9.8"
Rear Speaker Dimensions (WxHxD)
3.7" x 7.2" x 3.3"
Center Speaker Weight
2.67 lbs
Front Speaker Dimensions (WxHxD)
11.1" x 45.4" x 8.9"
Subwoofer Dimensions (WxHxD)
7.5" x 15.2" x 14.1"
Center Speaker Dimensions (WxHxD)
12.9" x 3.9" x 3.0"
Shipping Dimensions (WxHxD)
30.1" x 17.2" x 18.3"
Main Unit Weight
9.1 lbs
Front Speakers Weight
7.34 lbs each
Rear Speakers Weight
1.34 lbs each
Subwoofer Weight
11.9
Shipping Weight
55.1 lbs
REAR AUDIO / VIDEO INPUTS & OUTPUTS
AM Antenna Input
1
Digital Audio In (Optical)
2
LAN Port (RJ-45)
1
Speaker Output/Type
5/Push-type
Component Video Out
1
FM Antenna Input
1
Composite Video Out
1
HDMI™ Out
1
Subwoofer Output/Type
1/Push-type
VIDEO CAPABILITIES
Digital/Analog Conversion
162MHz/12bit
NTSC Hz
60Hz
Deep Color (HDMI™)
Yes
x.v.Color (HDMI™)
Yes
Composite Output
480i
HDMI™ Output
Up to 1080p (24 & 60Hz)
TUNER
AM/FM Tuner
Yes
AM Tuner Range (10kHz)
522 ~ 1620kHz
Radio Tuner Presets
50
FM Tuning Range (50kHz / 100kHz)
87.5 ~ 108.0 MHz
SPECIAL FEATURES
Netflix® Instant Streaming Ready
Yes
YouTube™
Yes
Vudu™ (Streaming)
Yes
Blu-ray BonusView
Yes
Blu-ray BD-Live™
Yes
Home Link (DLNA® Client)
Yes
NetCast™ Entertainment Access
Yes
Roxio® CinemaNow
Yes
Pandora® Internet Radio
Yes
Picasa™ Web Albums
Yes
AccuWeather®
Yes
MusicID®
Yes
Wireless LAN
b/g/n (2.4GHz only)
ARC
Yes
INCLUDED ACCESSORIES
Remote Control
1
A/V Cable
1 (RCA Type)
AM Antenna
1
Color-coded Speaker Cables
5
FM Antenna
1
Nero MediaHome 4 Essentials Software CD
1
User Manual
1
Remote Control Batteries
2 (Size AAA)
AUDIO CAPABILITIES
Dolby® Digital
Yes
Dolby® Digital Plus
Yes
DTS™
Yes
DTS-HD Master Audio™ Essential
Yes
LPCM
Yes
Sound Modes (DSP)
9 Modes
Digital/Analog Conversion
192KHz/24bit
Signal/Noise Ratio
100+ dB
Dolby® TrueHD
Yes
