Micro-portable LED Projector

  • WXGA (1,280 X 800)
  • 700 ANSI Lumens
  • Up to 30,000 Hour LED Life
  • Embedded HD DivX (Movies, Photo, Music) File Viewer (Office files)
Micro-portable LED Projector


  • System
    DLP (0.45")
    Native Resolution
    WXGA (1280x800)
  • Brightness (ANSI-Lumens)
    Contrast Ratio (FOFO)
  • Noise (High Brightness)
    34 dB(A)
    Noise (Normal)
    27 dB(A)
  • Noice (Economic)
    24 dB(A)
    Projection Lens (Focus)
  • Projection Lens (Zoom)
    Projection Image (Screen Size)
    20" - 100"
  • Projection Image (Standard)
    Projection Image (Throw Ratio)
  • Lamp (Type)
    Lamp (Life High Brightness)
    30,000 Hrs
  • Lamp (Life Economic)
    30,000 Hrs

General Specification

  • Menu Language
    Korean/English/French/Spanish/German/Italian/Swedish/Portguses/Chinese Simplified/Polish/Turkish/Russian/Arabic/Brazilian Portuguese
    Aspect Ratio Correction
    4:3/Just scan/Set by Pro/16:9/Cinema Zoom/Full/Zoom
  • Sound
    3W+3W Stereo
    Dimension (WxDxH)
    9.06" x 6.70" x 1.73"
  • Shipping Dimensions (WxDxH)
    18.1" x 10.4" x 5.3"
    2.98 lb
  • Shipping Weight
    5.95 lb
    Power Consumption
    120 W
  • Stand by Power
    0.5 W
    Power Supply
  • Operation Temp
    0º ~ 104º
    Input Signal Compatibility - Digital (HDMI)
  • Input Signal Compatibility - RGB
    Up to WSXGA+(1680x1050@60Hz)
    Input Signal Compatibility - Component Video
  • Input Signal Compatibility - Composite Video
    secam available

Input / Output Terminals

  • RGB in
    RGB(PC) Audio in
  • Component (YPbPr)
    RGB to Component In
    Audio out
    1 (3.5")
  • HDMI™
    1 (type A)

Special Features

  • 3D
    DLP 3D Ready (DPL Link), PC XGA 120Hz
    Digital Keystone Correction
  • Picture Still
    Auto Source Detection
  • Quick Power on/off
    Yes (Within 10 Seconds)
    Auto Sleep
  • Blank
    Yes (Blue, Green, Logo)
    Image Flip
    Horizontal / Vertical
  • Color Temperature
    Brilliant Color™
  • Black Level Control
    Expert Control
  • Gamma Correction
    Noise Reduction
  • Closed Caption
    Auto Input Search
  • Sleep Timer
    Auto Keystone
  • Automatic Standby

Added Features

  • File viewer: MS Office, PDF, TXT
    USB Host: MP3, HD DivX, Photo Paper


  • Cabinet Color
    Local Key
  • Kensington Lock
    Leg Stand


  • 3D Glasses
    DLP Link Glasses (Not Included)
    Carrying Pouch
  • Remote control
    Quick Setup Guide
  • Cable
    D-sub 15 & Phone to AV (Composite)
    Ceiling Mount
  • Lens Cap


  • Limited Warranty
    2 Years Parts and Labor

What people are saying

Rated 4 out of 5 by from Color quality is really good This is really good projector, small, easy to use. Only one problem is that Its says no signal or invalid format when I try to adjust my PC resolution over 1280 X 800. Otherwise everything is good.
Date published: 2016-02-04
Rated 5 out of 5 by from MODEL NAME: PA70G -Micro-portable LED Projector Product has been great for the family room Television viewing. Very happy with the projector.
Date published: 2014-12-20
Rated 4 out of 5 by from A nice portable projector This projector turns on and off really quickly. Being powered by an LED, you don't have to wait more than a few seconds for it to be ready to go. When you are done, it powers off and is ready to pack up almost as quickly. Works well with my 120 inch screen. At 700 lumens its one of the brightest portable LED projectors I have seen on the market.
Date published: 2013-06-26
  • y_2020, m_2, d_18, h_20
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.5
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_13
  • loc_en_US, sid_MD05000741, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 255ms


Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

My projector recently started to turn off and restart on its own every 3 to 5 minutes. Could someone explain why?

Asked by: R Adhitya
We regret the inconvenience you have experienced with this projector. The description provided suggests the possibility of the projector overheating. It is suggested to inspect the device for proper ventilation around its cabinet. If this does not resolve the matter, please contact our Customer Interactive Center at 800-243-0000 to further troubleshoot this situation.
Answered by: NeilE
Date published: 2016-12-13

Hi. I've been using and enjoying this product for over a year now but just recently it's lamp started projecting pink light. What's the cause?

Asked by: Maskani
We regret the inconvenience you have experienced with this projector. In times past, such symptoms can be caused by a bad lamp, or some related component. Please contact our Customer Interactive Center at 800-243-0000 for additional assistance in this matter.
Answered by: NeilE
Date published: 2016-05-04

Does the PA 70G projector accept PAL input on A/V

We have visitors from Europe that have a video recorder. It is in PAL format. The PA70G manual shows that the projector supports PAL formats, but we cannot select that setting. Does the projector automatically detect PAL format on the A/V input or can you provide instructions how to use the A/V input with PAL signals
Asked by: MvdB
We appreciate your interest in this projector. According to the specifications listed on page 57 of the owner’s manual, it appears that, along with the NTSC tuning band, this projector is also compatible with PAL-B, D, G, H, I / PAL M / PAL N and PAL 60. No adjustments should be required for changing between the various signals.
Answered by: NeilE
Date published: 2015-09-09

How to zoom on the LG PA70g?

I have my projector permently mounted on a ceiling fixture but when projected on my wall it makes about 117" screen. My projector screen is only 87" , is there any way to zoom in the picture so it only projects to a 87" size screen?
Asked by: Seksybob7
We regret the inconvenience you have experienced with this projector. How far away from the screen is this device located? From the description given, it sounds as if it has been placed well over 10 feet from the screen. Proper installation for an 87” screen should place the projector at about 8 3/4 feet.
Answered by: NeilE
Date published: 2014-03-13

Is there a way to download more apps from the LG app store?

When i go to the home screen on my LG smart projector, it has a tile for the LG app store, but it won't allow me to actually access it. Is there actually a way to access it to download more apps?
Asked by: Mitch1041
We appreciate your interest in this projector and its features. Make sure that this unit is connected to your network and router to allow access to the LG Apps Store. If you have additional questions, please contact our Customer Interactive Center at 800-243-0000.
Answered by: NeilE
Date published: 2013-10-22

Does the PA70G have the ability to turn power on given a signal input?

I can see that my PA70G can turn itself to standby/off when selected timer has elapsed without an input signal. I would like to be able to go from standby to on when an input signal is recieved. Can this projector do this? This would be a convenient feature for home theater set applications and would hopefully be as simple as firmware code/menu change. Thanks for your response Michael
Asked by: BubbaEarl
I apologize, but no; the TIMER options menu does not have a function available for the automatic activation of this device. There are only options for the automatic deactivation of this unit.
Answered by: NeilE
Date published: 2013-10-22

Does the LG PA70G allow color images to be viewed in black & white?

Asked by: Hunk
you should be able to just turn the color all the way to zero
Answered by: thebigdaddye
Date published: 2013-10-22

Can I stream Netflix movies directly on a PA75U projector?

We just bought a PA75U projector and we are very happy with it. What would make it even better is if we could stream Hulu plus and Netflix directly on it. Is that possible? Thank you, Anna
Asked by: annac
We appreciate your interest in this Projector. This device does not have the ability to receive Hulu Plus or Netflix on its own accord. You can either connect a computer that can receive these signals, or you may obtain the Smart TV Upgrader, model SP520 which will allow the Smart TV features which are available through the LG Apps Store. Information about this device can be viewed on our website at http://www.lg.com/us/blu-ray-players/lg-SP520-network-media-player.
Answered by: NeilE
Date published: 2013-10-22
